- Withstands 2000 VAC dielectric voltage
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150 Percent of rated current at a power factor of 75 Percent temperature rise
- 10 AWG terminal accommodation
- Wire restraint recess for both back and side wiring, greatly reduces the possibility of loosening the terminal connection
- Face color coding by voltage facilitates locating and mating of proper devices
- All-brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
- All-brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
- https://youtu.be/1DnPJu3QNw0
Specifications
Brand: Hubbell
Amperage Rating: 30 A
Dimensions: 3.28 x 1.7 x 1.31 in
NEMA Rating: L9-30R
Number of Poles: 2
Number of Wires: 3
Temperature Rating (Degrees F): -40 to 75 deg C
Terminal Type: Screw
Type: 1-Phase Grounding Heavy Duty Single Standard Screw Mount
Voltage Rating: 600 VAC
Color: Black
Country of origin: PR
Material: Nylon
Manufacturer Name: Hubbell
UNSPSC: 39121406
UPC: 00783585236070
Item FeaturesDry Location and Indoor Applications
Item Features
Item FeaturesUL 498|Federal Specification WC596|CSA C22.2 File No. 42|NEMA WD1/WD5|RoHS Compliant
