Part Number # HBL2811S
SKU # 2285743
Image provided may only be a representation of
final product and may include optional equipment
HBL2811S
Hubbell HBL2811S Locking Plug
Part Number # HBL2811S
SKU # 2285743
Hubbell HBL2811S Key Features
| Brand: | Hubbell |
|---|---|
| Part Number # : | HBL2811S |
| SKU #: | 2285743 |
| Amperage Rating: | 30, 30 A |
| Cord Diameter: | 0.35 to 1.15, 0.35 to 1.15 in |
| Dimensions: | 2.33 in Dia x 4.21 in L, 2.33 x 2.33 x 4.21 in |
| Enclosure: | IP20 |
| Horsepower: | 3, 3 hp |
| NEMA Rating: | L21-30P, NEMA L21-30P |
| Number of Poles: | 4 |
| Number of Wires: | 5 |
| Temperature Rating (Degrees F): | -40 to 75, -40 to 75 deg C |
| Terminal Type: | Screw |
| Type: | 3-Phase Grounding Male Shrouded Standard, 3-Phase Grounding Male Shrouded Standard Cord Mount |
| Country of origin: | PR, US |
| Material: | Composite, Nylon |
| Manufacturer Name: | Hubbell |
| UNSPSC: | 39121402 |
| UPC: | 00783585235103 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Hubbell HBL2811S Locking Plug
Brand: Hubbell
Part Number: HBL2811S
Wiring Device-Kellems Twist-Lock Safety-Shroud Locking Plug, 3-Phase Grounding Male Shrouded Standard Cord Mount, 120/208 VAC, 30 A, 3 hp, 4 Pole, 5 Wires, L21-30P NEMA Rating, IP20 Enclosure, 0.35 to 1.15 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Black/White, 2.33 x 2.33 x 4.21 in
Additional Description: HUBW-HBL2811S (N) LKG S/SHRD PLUG, 30A 3P 120/208V,L21-30P NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Twist-Lock®,Safety-Shroud® Plug, 30A, 3 Phase Y 120/208V AC, 4-Pole, 5 Wire Grounding, NEMA L21 and white nylon body, white PBT shroud
HBL2811S Application
Power Connection and Indoor Dry Environment ApplicationsHBL2811S Item Features
- Ribbed nylon housing provides a secure grip and impact and chemical resistance
- Superior cord grip design for flat cable protects terminations from excess strain
- Clear, funnel shaped wire entry for ease of termination
- Integral dust shield protects wiring chamber from dust or contaminants
- https://youtu.be/1DnPJu3QNw0
HBL2811S Standards
RoHS Compliant|CSA C22.2 No. 42|Federal Specification W-C-596|UL 498SKU #2285743Part Number #HBL2811SUNSPSC39121402UPC00783585235103
