- On piece brass contact sleeves
- Sequential contact engagement to prevent a momentary over voltage on components
- Super tough insulated non-metallic house for impact and chemical resistance
- Nickel plated brass clamp nut
- Stainless steel terminal screws, assembly screws and cord clamp screws
- Thermoset polyester contact carrier and retainer
- Epoxy painted aluminum lock ring
- Gasketed sealing ring provides watertight seal
Specifications
Brand: Hubbell
Amperage Rating: 60 A
Dimensions: 4.49 in Dia x 10.15 in L
Enclosure: IP67
NEMA Rating: 4X/12, NEMA 4X/12
Number of Poles: 3
Number of Wires: 4
Series: HBL
Temperature Rating (Degrees F): -40 to 75, -40 to 75 deg C
Terminal Type: Pressure Screw
Type: 1-Phase Grounding Heavy Duty Male Non-NEMA Portable Reverse Standard Watertight, 1-Phase Grounding Heavy Duty Male Non-NEMA Portable Reverse Standard Watertight Cord Mount
Voltage Rating: 120/240 VAC, 125/250
Color: Orange
Country of origin: US
Material: Composite
Manufacturer Name: Hubbell
UNSPSC: 39121402
UPC: 00783585012728
Item FeaturesHigh Ampacity Connections Applications
Item Features
Item FeaturesRoHS Compliant|CSA C22.2 File No. 182.1|IEC 60309-1|IEC 309-1/309-2|UL 498 File No. E146032
