Part Number # HBL9379
SKU # 2283627
Image Disclaimers Message
Brand: Hubbell
HBL9379
Hubbell HBL9379 Straight Blade Plug
Part Number # HBL9379
SKU # 2283627
$108.50 / Each
Typical price:$166.00 / Each
Hubbell HBL9379 Key Features
| Brand: | Hubbell |
|---|---|
| Part Number # : | HBL9379 |
| SKU #: | 2283627 |
| Amperage Rating: | 50, 50 A |
| Cord Diameter: | 0.625 to 1.187, 0.625 to 1.187 in |
| Dimensions: | 4.34 in H x 2.73 in W x 1.87 in D, 4.34 x 2.75 x 1.88 in |
| Enclosure: | IP20 |
| Horsepower: | 5, 5 hp |
| NEMA Rating: | 7-50P, NEMA 7-50P |
| Number of Poles: | 2 |
| Number of Wires: | 3 |
| Temperature Rating (Degrees F): | -40 to 75 deg C |
| Terminal Type: | Screw |
| Type: | 1-Phase Angled Grounding Heavy Duty Male, 1-Phase Angled Grounding Heavy Duty Male Cord Mount |
| Color: | Black, Black/White |
| Country of origin: | US |
| Material: | Nylon |
| Manufacturer Name: | Hubbell |
| UNSPSC: | 39121402 |
| UPC: | 00783585015545 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$108.50 / Each
Typical price:$166.00 / Each
Quantity:
- Hubbell Wiring Device-Kellems, HBL9379, Straight Blade Plug, 1-Phase Angled Grounding Heavy Duty Male Cord Mount, 277 V AC, 50 A, 5 hp, 2 Pole, 3 Wires, 7-50P NEMA Rating, Commercial/Industrial Grade, IP20 Enclosure, 0.625 to 1.187 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Black, 4.34 x 2.75 x 1.88 in Dimensions
HBL9379 Application
Indoor Dry Environment, Commercial and Industrial ApplicationsHBL9379 Item Features
- Four position assembly
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise
- Withstands 2000 VAC minimum dielectric voltage
- All portable cord
- Indoor dry unless protected by additional mean environmental conditions
- Cord mounted
- Reinforced thermoplastic polyester blade holder
- Steel zinc plated terminal screw
- Brass contact blades
- https://youtu.be/1DnPJu3QNw0
HBL9379 Standards
RoHS Compliant|UL 498|NEMA WD1/WD5|CSA CertifiedSKU #2283627Part Number #HBL9379UNSPSC39121402UPC00783585015545
