Brand: Hubbell
Hubbell OC-2CG Duraloy 5 Conduit Body
Image Disclaimers Message
Brand: Hubbell
Hubbell OC-2CG Duraloy 5 Conduit Body
Brand: Hubbell
Hubbell OC-2CG Duraloy 5 Conduit Body
Part #:OC-2CG
SKU #: 2368733
$23.42/EA
Key Features
Part #:OC-2CG
SKU #: 2368733
Brand: Hubbell
Capacity: 7, 7 cu-in
Dimensions: 6-1/8 in L x 1-5/8 in W x 1-5/8 in H
Finish: Powder Coated
Form: 85
Hub Size: 3/4, 3/4 in
$23.42/EA
- Tapered threaded hubs (NPT)
- Stainless steel screws on stamped and cast covers
- Interchangeable with competitive products
- Suitable for wet locations when used with gasketed covers
- Copper free aluminum (less than 4/10 of 1%)
- Electrostatically applied powder coated
Specifications
Brand: Hubbell
Capacity: 7, 7 cu-in
Dimensions: 6-1/8 in L x 1-5/8 in W x 1-5/8 in H
Finish: Powder Coated
Form: 85
Hub Size: 3/4, 3/4 in
Series: O Series
Type: Type C, Type-C
Color: Gray
Connection type: Tapered NPT
Country of origin: MX
Material: Aluminum
Manufacturer Name: Hubbell
UNSPSC: 39131708
UPC: 00783936049236
Hubbell OC-2CG Duraloy 5 Conduit Body
Killark Duraloy 5 Conduit Body, Type-C, Series: O Series, 3/4 in Hub, 2 Hubs, 7 cu-in Capacity, 85 Form, Tapered NPT Connection, Aluminum, Powder Coated, Gray, 6-1/8 in L x 1-5/8 in W x 1-5/8 in H Dimensions
Additional Description: KILL-OC-2CG BODY,CVR,GASK 3/4"" C AL
Catalog Description: O Series/Duraloy 5 Series Aluminum Conduit Body with Cover And Gasket- C Type - Hub Size ¾" - Volume 7.0 cu in
Item FeaturesFor to provide access to conductors for pulling, splicing and maintenance and threaded for rigid conduit and IMC
Item Features
Item FeaturesCSA Certified|UL Listed|UL File No. E3397|CSA File No. LR11852|Federal Specification W-C-586D/A-A 50563|NEC 501.10(b)/502.10/503.10 Class I Div 2
