- 1.01 in Dia throat
- Hubbells nylon cord connectors resist most common industrial corrosive and provide effective pullout protection in a lightweight design
- They are ideal for any application where weight, conductivity or corrosion may be an issue
- Machined threads provide a strong positive seal, the tapered interior dome easily drives the bushing into the connector body
- Lubricated neoprene bushing compresses easily for a liquidtight seal and added pull-out protection
- Patented GOTCHA ring incorporates a split hinge design to prevent friction and provide strain relief, also color coded for sizing identification
- 1.09 to 1.14 in recommended knockout hole
- https://youtu.be/6SdOpBP_CJk
Specifications
Brand: Hubbell
Cable Openings: 0.88 to 1, 0.88 to 1 in
Dimensions: 1.88 in L x 1.88 in W x 2.45 in H
Finish: Smooth
Number of Conductors: 1
Series: SHC
Temperature Rating (Degrees F): -30 to 225, -30 to 225 deg F
Trade Size: 1, 1 in, 1 in NPT
Type: Form 4 Standard Duty, Form 4 Standard Duty Straight
Cable type: Jacketed
Color: Black/Gray
Connection type: MNPT, Straight Male
Country of origin: PR
Material: Nylon
Manufacturer Name: Hubbell
UNSPSC: 39121431
UPC: 00783585451800
Hubbell SHC2043CR Cord Connector
Wiring Device-Kellems Cord Connector, Form 4 Standard Duty Straight, 1 in Trade, 1 Conductor, Cable Openings: 0.88 to 1 in, Jacketed Cable, MNPT Connection, Nylon, Smooth, Black/Gray, -30 to 225 deg F, 1.88 in L x 1.88 in W x 2.45 in H Dimensions
Additional Description: HUBW-SHC2043CR CORDCON, STR ML, .88-1.00, 1"", NYL, BK"" NYL, BK
Catalog Description: Kellems Wire Management, Cord Connectors, Straight Male, .88-1.00", 1", Nylon
Item FeaturesFor wet location when used with a listed nylon washer between box and fitting, hazardous location Applications
Item Features
Item FeaturesCSA Certified|RoHS Compliant|UL 514B|Title 46-Part 111|UL94 V-2 Flammability Rating
