Part Number # UGP-20232QW
SKU # 2304552
Image Disclaimers Message
Brand: Hubbell
UGP-20232QW
Hubbell UGP-20232QW Straight Blade Plug
Part Number # UGP-20232QW
SKU # 2304552
$406.68 / Each
Hubbell UGP-20232QW Key Features
| Brand: | Hubbell |
|---|---|
| Part Number # : | UGP-20232QW |
| SKU #: | 2304552 |
| Amperage Rating: | 20, 20 A |
| Dimensions: | 6-5/8 in L x 2-3/8 in W x 1-7/8 in H |
| Enclosure: | NEMA 3/4/4X/7B/7C/7D/9F/9G |
| NEMA Rating: | NEMA 6-20P |
| Number of Poles: | 2 |
| Number of Wires: | 3 |
| Series: | UGP |
| Type: | 1-Phase Explosionproof |
| Color: | Gray |
| Country of origin: | CN |
| Material: | Copper Free Aluminum |
| Manufacturer Name: | Hubbell |
| UNSPSC: | 39121402 |
| UPC: | 00783936076676 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$406.68 / Each
Quantity:
- Killark, UGP-20232QW, Straight Blade Plug, 1-Phase Explosionproof, Series: UGP, 250 V AC, 20 A, 2 Pole, 3 Wires, NEMA 6-20P NEMA Rating, NEMA 3/4/4X/7B/7C/7D/9F/9G Enclosure, Copper Free Aluminum, Gray, 6-5/8 in L x 2-3/8 in W x 1-7/8 in H Dimensions
UGP-20232QW Application
Petroleum Refineries, Chemical Plants, Wet, Damp Areas, Corrosive, Hazardous Environment, Petroleum Plants, Grain Elevators, Feed Mills, Flour And Feed Mills and Indoor and Outdoor LocationsUGP-20232QW Item Features
- Factory sealed chamber in UGR receptacle contains switchs arcing components
- Spring loaded receptacle cover closes when plug is removed
- Copper-free aluminum (less than 4/10 of 1 Percent) alloy resists corrosion
- Electrostatically applied and baked powder epoxy/polyester finish
- ACCEPTOR plugs conform to NEMA configurations, while its "turn to engage" feature locks in plug and can be used to prevent accidental disengagement of critical equipment
- Plugs for use with type S/SO/ST/STO heavy duty cord
UGP-20232QW Standards
CSA Certified|cCSAus File No. LR14667|UL File No. E91049, E53660|Class I, Div 1 and 2, Group C, D, Class I, Zone 1 and 2, Group IIB, IIA, Class II, Div 1 and 2, Group F, G, Class III, Div 1 and 2SKU #2304552Part Number #UGP-20232QWUNSPSC39121402UPC00783936076676
