Brand: Hubbell
UGR0-20231QW
Hubbell UGR0-20231QW Interchangeable Blade Receptacle
Part Number # UGR0-20231QW
SKU # 2278236
$1049.68 / Each
Hubbell UGR0-20231QW Key Features
| Brand: | Hubbell |
|---|---|
| Part Number # : | UGR0-20231QW |
| SKU #: | 2278236 |
| Amperage Rating: | 20, 20 A |
| Dimensions: | 6 in H x 3 in W x 4-3/16 in D |
| Horsepower: | 1 |
| NEMA Rating: | NEMA 3/7CD/9FG, NEMA 5-20R/3/7BCD/9FG |
| Number of Poles: | 2 |
| Number of Wires: | 3 |
| Series: | UGR, UGRO |
| Temperature Rating (Degrees F): | -40 to 75 |
| Terminal Type: | Quick Wire, Screw |
| Type: | 1-Gang Explosionproof |
| Color: | Gray |
| Material: | Copper Free Aluminum, Copper-Free Aluminum |
| Manufacturer Name: | Hubbell |
| UNSPSC: | 39121406 |
| UPC: | 00783936125862 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1049.68 / Each
Quantity:
- Killark, UGR0-20231QW, Acceptor Receptacle, Series: UGR, 125 V AC, 20 A, 2 Pole, 3 Wires, NEMA 3/7CD/9FG NEMA Rating, Quick Wire Terminal, Copper Free Aluminum
UGR0-20231QW Specifications
- All external hardware is 316 stainless steel to provide low maintenance and long life
- Factory sealed chamber in UGR receptacle contains switch's arcing components
- No additional external seals are required, except in group b applications
- Aluminum interchangeable blade style
- Copper-free aluminum
- 14 to 10 AWG
- 0.05 in brass strap
UGR0-20231QW Item Features
- Factory sealed chamber in UGR receptacle contains switchs arcing components
- Spring loaded receptacle cover closes when plug is removed
- Copper-free aluminum (less than 4/10 of 1 Percent) alloy resists corrosion
- Electrostatically applied and baked powder epoxy/polyester finish
- ACCEPTOR plugs conform to NEMA configurations, while its "turn to engage" feature locks in plug and can be used to prevent accidental disengagement of critical equipment
- Plugs for use with type S/SO/ST/STO heavy duty cord
