Part Number # XSD-01
SKU # 2389525
Brand: Hubbell
XSD-01
Hubbell XSD-01 Manual Motor Starting Switch
Part Number # XSD-01
SKU # 2389525
$602.27 / Each
Hubbell XSD-01 Key Features
| Brand: | Hubbell |
|---|---|
| Part Number # : | XSD-01 |
| SKU #: | 2389525 |
| Dimensions: | 4-5/8 in H x 3 in W x 1-3/4 in D |
| Frequency Rating: | 60 Hz |
| Motor Power: | 1 hp at 115 to 230 VAC |
| Number of Poles: | 1 |
| Phase: | 1 |
| Reset Type: | Lever |
| Series: | XSD |
| Type: | 1-Gang Non-Factory Sealed |
| Country of origin: | US |
| Material: | Copper-Free Aluminum |
| Manufacturer Name: | Hubbell |
| UNSPSC: | 39121521 |
| UPC: | 00783936932002 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$602.27 / Each
Quantity:
Hubbell XSD-01 Manual Motor Starting Switch
Brand: Hubbell
Part Number: XSD-01
Killark Manual Motor Starting Switch, 1-Gang Non-Factory Sealed, Series: XSD, 230 VAC, 60 Hz Frequency, 1 hp at 115 to 230 VAC Motor, 1 Pole, Lever Reset, 1 ph, Copper-Free Aluminum, 4-5/8 in H x 3 in W x 1-3/4 in D Dimensions
Additional Description: KILL-XSD-01 CVR SWITCH 1GANG 1P OVERLD PROT
Catalog Description: CVR SWITCH ASSY 1GANG 1P XSD/XSX/FXSD/FXSX SERIES CONTROLS MANUAL MOTOR STARTING SWITCH
XSD-01 Application
Provides manual starting and stopping of small AC or DC motors, motor running protection when overload heaters are usedXSD-01 Item Features
- Operating shaft is stainless steel
- Multiple gang assemblies available in combination with pilot lights, pushbuttons and switches on request
- Ground flange joint between bolted cover and box provide required flame path
- Provisions for padlocking switch in either "ON" or "OFF" position is standard
XSD-01 Standards
CSA File No. LR11714|FM File No. 25219|Class I, Divisions 1 and 2, Groups C, D|Class I, Zones 1 and 2, Groups IIB, IIA|Class II, Divisions 1 and 2, Groups E, F, G|Class III, Divisions 1 and 2|PROP65: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.SKU #2389525Part Number #XSD-01UNSPSC39121521UPC00783936932002
Image provided may only be a representation of final product and may include optional equipment
