Part Number # XSX-52
SKU # 2305018
XSX-52
Hubbell XSX-52 Manual Motor Starting Switch
Part Number # XSX-52
SKU # 2305018
$586.59 / Each
Hubbell XSX-52 Key Features
| Brand: | Hubbell |
|---|---|
| Part Number # : | XSX-52 |
| SKU #: | 2305018 |
| Action: | Manual |
| Amperage Rating: | 30/20 A |
| Dimensions: | 3 in W x 4 in D x 6 in H |
| Enclosure Type: | NEMA 3 |
| Frequency Rating: | 60 Hz |
| Motor Power: | 3 hp |
| Number of Poles: | 2 |
| Phase: | 1 |
| Reset Type: | Lever |
| Series: | XSX |
| Type: | Feed-Through |
| Country of origin: | US |
| Material: | Copper-Free Aluminum |
| Manufacturer Name: | Hubbell |
| UNSPSC: | 39121521 |
| UPC: | 00783936933504 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$586.59 / Each
Quantity:
- Killark, XSX-52, Manual Motor Starting Switch, Feed-Through, Series: XSX, 600 V AC, 30/20 A, 60 Hz Frequency, 3 hp Motor, 2 Pole, Lever Reset, 1 ph, Manual Action, NEMA 3 Enclosure, Copper-Free Aluminum, 3 in W x 4 in D x 6 in H Dimensions
XSX-52 Application
Motor Running Without Overload Protection ApplicationsXSX-52 Item Features
- Enclosures are cast copper-free aluminum alloy
- Provisions for padlocking switch in either "ON" or "OFF" position is standard
- Operating shaft is stainless steel
- FXSX Series require no external seals (factory sealed) and are NEMA 3 (raintight) rated
- 3/4 in hub
- Provides manual starting and stopping of small AC or DC motors
- Class 2510, type K, single gang, 1-phase
- Multiple gang assemblies available in combination with pilot lights, pushbuttons and switches on request
- 2 hp at 115 VAC, 2 hp at 200 to 230 VAC, 3 hp at 460 to 575 VAC power rating
- XSX Series (without overload protection) are ideally suited for across the line applications where a positive disconnect means is required
- Ground flange joint between bolted cover and box provide required flame path
XSX-52 Standards
UL File No. E12379|CSA File LR11714 Certified|FM File 25219 Approved|Class 1, Zones 1 and 2, Groups llB, llA|Class II, Divisions 1 and 2, Groups E, F, G|Class lll|UL File E53360/E12379|PROP65: This product can expose you to chemicals including Lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govSKU #2305018Part Number #XSX-52UNSPSC39121521UPC00783936933504
Image provided may only be a representation of final product and may include optional equipment
