Part Number # SLU-225
SKU # 2264538
SLU-225
ILSCO SLU-225 ILSCO ClearChoice Mechanical Lug
Part Number # SLU-225
SKU # 2264538
Ilsco SLU-225 Key Features
| Brand: | Ilsco |
|---|---|
| Part Number # : | SLU-225 |
| SKU #: | 2264538 |
| Conductor Size: | 4/0 to 2, 4/0 to 2 AWG |
| Conductor Type: | Copper |
| Dimensions: | 2-5/8 in L x 1 in W |
| Finish: | Electrolytic |
| Series: | SLU |
| Specifications: | 7/32 in Hex Socket Screw, V-Bottom Collar |
| Temperature Rating (Degrees F): | 90, 90 deg C |
| Tongue Size: | 1.1563 in L x 1 in W |
| Tongue Type: | Offset/Straight, Straight/Offset |
| Type: | 1-Conductor Compact |
| Country of origin: | IN |
| Material: | Copper |
| Manufacturer Name: | ECM Industries |
| UNSPSC: | 39121408 |
| UPC: | 00783669833751 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ILSCO SLU-225 ILSCO ClearChoice Mechanical Lug
Brand: Ilsco
Part Number: SLU-225
ILSCO ClearChoice Mechanical Lug, 1-Conductor Compact, Series: SLU, Copper Conductor, 4/0 to 2 AWG Conductor, 5/16 in Stud, 1 Bolt Holes, 1.1563 in L x 1 in W Tongue, Straight/Offset Tongue, 2000 VAC, Specifications: 7/32 in Hex Socket Screw, V-Bottom Collar, 90 deg C, Copper, Electrolytic, 2-5/8 in L x 1 in W
Additional Description: ILSC-SLU-225 CU MEC 4/0-2 11/32 B UL CSA OF FSET
Catalog Description: Copper Mechanical Lug Offset, Conductor Range 4/0-2, 1 Port, 1 Hole, 5/16in Bolt Size, UL, CSA
SLU-225 Application
For terminating connectorSLU-225 Item Features
- Manufactured from electrolytic copper tubing and strip stock
- Compact design
- Range taking for reduced inventories and flexibility
- Re-usable
- Contact factory for listed wire combinations
- Compact design saves space and reduces installation time
- Wires are wedged between arched pressure bar and collar establishing positive contact and firm permanent grip
- Provides maximum conductivity and strength
- Suitable for use in circuits rated 35 kV or less, proper high voltage spacing and insulation techniques must be used
- Ensures reliability for copper conductor
- A - UL listed combinations (2) 10 AWG or (2) 12 AWG stranded or (2) 14 AWG stranded or (1) 12 AWG stranded and (1) 14 AWG stranded or (1) 10 AWG stranded and (1) 12 AWG stranded conductor size
- B - UL listed combinations (1) 8 AWG stranded and (1) 4 AWG stranded or (1) 8 AWG stranded and (1) 6 AWG stranded or (2) 4 AWG stranded or (3) 8 AWG stranded or (3) 6 AWG stranded or (2) 8 AWG stranded and (1) 4 AWG stranded or (2) 8 AWG stranded and (1) 6 AWG stranded or (1) 6 AWG stranded and (1) 4 AWG stranded or (2) 6 AWG stranded
- V-bottom collar
SLU-225 Standards
CSA File No. LR-29601|UL 486A/B/453G|E6207SKU #2264538Part Number #SLU-225UNSPSC39121408UPC00783669833751
Image provided may only be a representation of final product and may include optional equipment
