Part Number # WP1010HMXD
SKU # 2253367
Image provided may only be a representation of
final product and may include optional equipment
WP1010HMXD
Intermatic WP1010HMXD Weatherproof While-In-Use Cover
Part Number # WP1010HMXD
SKU # 2253367
Intermatic WP1010HMXD Key Features
| Brand: | Intermatic |
|---|---|
| Part Number # : | WP1010HMXD |
| SKU #: | 2253367 |
| Insulation: | Neoprene Gasket |
| Mounting Orientation: | Horizontal |
| Number of Gangs: | 1 |
| Number of Outlets: | 1 |
| Series: | WP1000MX |
| Temperature Rating (Degrees F): | -51, -51 deg C |
| Type: | Heavy Duty |
| Country of origin: | IN |
| Depth: | 3-1/8, 3-1/8 in |
| Length: | 4.37, 4.37 in |
| Material: | Die Cast Aluminum, Die-Cast Aluminum |
| Mounting type: | Surface |
| Width: | 5-3/4, 5-3/4 in |
| Manufacturer Name: | Intermatic |
| UNSPSC: | 39121304 |
| UPC: | 00078275130128 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Intermatic WP1010HMXD Weatherproof While-In-Use Cover
Brand: Intermatic
Part Number: WP1010HMXD
Intermatic Weatherproof While-In-Use Cover, Heavy Duty, 1 Outlets, 1 Gangs, 4.37 in Length, 5-3/4 in Width, 3-1/8 in Depth, Rectangular Shape, Receptacle Cover, -51 deg C, Neoprene Gasket Insulation, Horizontal Mounting, Surface Mounting, Die-Cast Aluminum, Gray
Additional Description: INTR-WP1010HMXD EXTRA-DUTY DIE-CAST IN-USE WEATHERPROOF COVER, SINGLE-GANG, HRZ, 3.125"" GRAY Hrz, 3.125" Gray Cover 3-1/8"" DEEP W/ (WP17) INSERTS
Catalog Description: Extra-Duty Die-Cast In-Use Weatherproof Cover, Single-Gang, Hrz, 3.125" Gray
WP1010HMXD Application
Sports Fields, Commercial, Agricultural and Signage, Residential and Industrial ApplicationsWP1010HMXD Includes
WP17 FlexiGuard Duplex, GFCI Inserts, Knockout, Gasket, Mounting Screws, Knockouts, Base and Cover AssemblyWP1010HMXD Item Features
- Meets requirements for cold impact testing -60 deg F (-51 deg C)
- Lockable hasp, All models accept up to 1/4 in (6 mm) dia shank
- Impact rated 12 lbf. impact test to ensure cover remains intact
- Reinforced hinge pin designed to exceed 40 lbf. hinge hang/stress test
WP1010HMXD Standards
2014 NEC Article 406.9(B)(1), NEMA 3R, UL Listed, CSA, CEC Rule 26-702WP1010HMXD Warranty
1 yearSKU #2253367Part Number #WP1010HMXDUNSPSC39121304UPC00078275130128
