Part Number # 0034602
SKU # 2457084
Image Disclaimers Message
0034602
LAPP USA 0034602
Part Number # 0034602
SKU # 2457084
$1.33 / Feet
Typical price:$1.70 / Feet
LAPP 0034602 Key Features
| Brand: | LAPP |
|---|---|
| Part Number # : | 0034602 |
| SKU #: | 2457084 |
| Conductor Size: | 20 AWG |
| Conductor Type: | Bare Stranded Copper |
| Jacket Color: | Pebble Gray |
| Jacket Material: | PVC |
| Number of Conductors: | 2 |
| Outside Diameter: | 0.22 in |
| Resistance: | 20 GOhm |
| Series: | LiYCY |
| Temperature Rating (Degrees F): | -40 to 80 deg C |
| Type: | Multi-Pair Unshielded Multi-Conductor |
| Insulation material: | PVC |
| Manufacturer Name: | Lapp Group |
| UNSPSC: | 0 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1.33 / Feet
Typical price:$1.70 / Feet
Quantity:
- UNITRONIC Cable, Multi-Pair Unshielded Multi-Conductor, Series: LiYCY, 250 V AC, 2 Conductors, Bare Stranded Copper Conductor, 20 AWG Conductor, 0.22 in OD, 20 GOhm Resistance, PVC Insulation, PVC Jacket, Pebble Gray Jacket, -40 to 80 deg C
0034602 Application
Rs-232, Data Buses, Process Control Instrumentation, Broadcast, Low-Voltage Signaling and Interconnect0034602 Item Features
- Extended temperature range of -40 to 80 deg C
- European color code DIN 47100
- Flexible for easy installation
- Nominal 0.65 m H/km inductance
- 37 pF/ft mutual capacitance
- 1500 VAC test voltage
- -5 to 70 deg C temperature for flexible use
- RAL 7032 pebble gray
0034602 Standards
RoHS Compliant|VDE CertifiedSKU #2457084Part Number #0034602UNSPSC0UPC
