772013
Lutze 772013 Control Cable
Part Number # 772013
SKU # 2408928
$146.48 / Each
Typical price:$191.76 / Each
LUTZE 772013 Key Features
| Brand: | LUTZE |
|---|---|
| Part Number # : | 772013 |
| SKU #: | 2408928 |
| Connector Type: | Screw Terminal |
| Enclosure Type: | IP30 |
| Environmental Conditions: | 5 to 90% Non-Condensing Relative Humidity |
| Interface: | 10/100/1000BaseTX |
| Network Type: | EtherNet |
| Port Type: | 5 RJ45 |
| Protocol: | IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet, IEEE 802.3x, IEEE 802.3az, IEEE 802.1p, IEC 60068-2-32, IEC 60068-2-27, IEC 60068-2-6 |
| Temperature Rating (Degrees F): | -40 to 75 deg C |
| Type: | Unmanaged |
| Country of origin: | TW |
| Height: | 104 mm |
| Mounting type: | DIN Rail/Wall |
| Power supply: | 7 to 52 V DC |
| Switching capacity: | 10 Gbps |
| Width: | 30 mm |
| Manufacturer Name: | LUTZE Inc |
| UNSPSC: | 26121603 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$146.48 / Each
Typical price:$191.76 / Each
Quantity:
- LUTZE, 772013, Network Switch, Unmanaged, 10/100/1000BaseTX Interface, 5 RJ45 Port, 10 Gbps Switching, IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet, IEEE 802.3x, IEEE 802.3az, IEEE 802.1p, IEC 60068-2-32, IEC 60068-2-27, IEC 60068-2-6 Protocol, 1000 Mbit Forwarding Rate, Network: Ethernet, Screw Terminal Connector, 7 to 52 V DC Supply, IP30 Enclosure, DIN Rail/Wall Mounting, 30 mm Width, 104 mm Height, -40 to 75 deg C, Environmental Conditions: 5 to 90% Non-Condensing Relative Humidity
772013 Item Features
- Output alarm relay
- DIN rail mountable TS35/Wall mounting capabilities
- Improved ESD (electro Static Discharge) protection +/- 6 kV DC
772013 Standards
CE|FCC Part 15 Class A|UKCA|cULus (E332878)|IEEE 802.3azSKU #2408928Part Number #772013UNSPSC26121603UPC
