Part Number # 772015
SKU # 2408929
Image Disclaimers Message
Brand: LUTZE
772015
Lutze 772015 Control Cable
Part Number # 772015
SKU # 2408929
$214.39 / Each
Typical price:$280.65 / Each
LUTZE 772015 Key Features
| Brand: | LUTZE |
|---|---|
| Part Number # : | 772015 |
| SKU #: | 2408929 |
| Connector Type: | Screw Terminal |
| Enclosure Type: | IP30 |
| Environmental Conditions: | 5 to 90% Non-Condensing Relative Humidity |
| Interface: | 10/100/1000BaseTX |
| Network Type: | EtherNet |
| Port Type: | 8 RJ45 |
| Protocol: | IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet, IEEE 802.3x, IEEE 802.3az, IEEE 802.1p, IEC 60068-2-32, IEC 60068-2-27, IEC 60068-2-6 |
| Temperature Rating (Degrees F): | -40 to 75 deg C |
| Type: | Unmanaged |
| Country of origin: | TW |
| Height: | 135 mm |
| Mounting type: | DIN Rail/Wall |
| Power supply: | 9 to 52 V DC |
| Switching capacity: | 10 Gbps |
| Width: | 32 mm |
| Manufacturer Name: | LUTZE Inc |
| UNSPSC: | 26121603 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$214.39 / Each
Typical price:$280.65 / Each
Quantity:
- LUTZE, 772015, Network Switch, Unmanaged, 10/100/1000BaseTX Interface, 8 RJ45 Port, 10 Gbps Switching, IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet, IEEE 802.3x, IEEE 802.3az, IEEE 802.1p, IEC 60068-2-32, IEC 60068-2-27, IEC 60068-2-6 Protocol, 1000 Mbit Forwarding Rate, Network: Ethernet, Screw Terminal Connector, 9 to 52 V DC Supply, IP30 Enclosure, DIN Rail/Wall Mounting, 32 mm Width, 135 mm Height, -40 to 75 deg C, Environmental Conditions: 5 to 90% Non-Condensing Relative Humidity
772015 Item Features
- Output alarm relay
- Narrow 32mm housing width
- Improved ESD (electro Static Discharge) protection +/- 6 kV DC
772015 Standards
CE|FCC Part 15 Class A|UKCA|cULus (E332878)|IEEE 802.3azSKU #2408929Part Number #772015UNSPSC26121603UPC
