Part Number # 772017
SKU # 2408930
Image Disclaimers Message
772017
Lutze 772017 Control Cable
Part Number # 772017
SKU # 2408930
$435.92 / Each
Typical price:$570.66 / Each
LUTZE 772017 Key Features
| Brand: | LUTZE |
|---|---|
| Part Number # : | 772017 |
| SKU #: | 2408930 |
| Connector Type: | Screw Terminal |
| Enclosure Type: | IP30 |
| Environmental Conditions: | 5 to 90% Non-Condensing Relative Humidity |
| Interface: | 10/100/1000BaseTX |
| Network Type: | EtherNet |
| Port Type: | 16 RJ45 |
| Protocol: | IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1p, IEC 60068-2-32 (free fall), IEC 60068-2-27 (shock), IEC 60068-2-6 (vibration) |
| Temperature Rating (Degrees F): | -40 to 75 deg C |
| Type: | Unmanaged |
| Country of origin: | TW |
| Height: | 152 mm |
| Mounting type: | DIN Rail/Wall |
| Power supply: | 10 to 52 V DC |
| Switching capacity: | 10 Gbps |
| Width: | 66 mm |
| Manufacturer Name: | LUTZE Inc |
| UNSPSC: | 26121603 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$435.92 / Each
Typical price:$570.66 / Each
Quantity:
- LUTZE, 772017, Network Switch, Unmanaged, 10/100/1000BaseTX Interface, 16 RJ45 Port, 10 Gbps Switching, IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1p, IEC 60068-2-32 (free fall), IEC 60068-2-27 (shock), IEC 60068-2-6 (vibration) Protocol, 1000 Mbit Forwarding Rate, Network: Ethernet, Screw Terminal Connector, 10 to 52 V DC Supply, IP30 Enclosure, DIN Rail/Wall Mounting, 66 mm Width, 152 mm Height, -40 to 75 deg C, Environmental Conditions: 5 to 90% Non-Condensing Relative Humidity
772017 Item Features
- Output alarm relay
- Narrow 66mm housing width
- Improved ESD (electro Static Discharge) protection +/- 6 kV DC
772017 Standards
CE|FCC Part 15 Class A|UKCA|cULus (E332878)|IEEE 802.3azSKU #2408930Part Number #772017UNSPSC26121603UPC
