- Unique integral DIN-rail adapters for 600 V 30 and 60 a fuse blocks
- Full barrier design (30 and 60 A) increases pole to pole safety
- Unique adder-block design (30 and 60 A) for design flexibility
- Spring reinforcing standard for all 30 and 60 A clips
- Features high conductivity copper alloy fuse clips
- Cool running high amperage (100 to 600 A) connectors
- 200 kA short circuit current rating
Specifications
Brand: Mersen
Amperage Rating: 100, 100 A
Class: T
Dimensions: 4.78 in L x 4.38 in W x 1.95 in H
Number of Phases: 3
Number of Poles: 3
Suitable For Use With: A6T Series Fuse
Type: Open Style
Voltage Rating: 600, 600 VAC/VDC
Wire Size: 12 to 2/0, 12 to 2/0 AWG
Connection type: Box Lug
Country of origin: MX
Material: Phenolic
Mounting type: DIN Rail
Manufacturer Name: MERSEN
UNSPSC: 39121629
UPC: 00782001675912
Item Features
Item FeaturesRoHS Compliant|UL 4248-15 File No. E52283|CSA C22.2 Class 6225/32169
