Part Number # USCC1I-AC300
SKU # 2450507
Image Disclaimers Message
USCC1I-AC300
Mersen Fuses USCC1I-AC300
Part Number # USCC1I-AC300
SKU # 2450507
$973.80 / 12Each
Typical price:$1794.94 / Each
Mersen USCC1I-AC300 Key Features
| Brand: | Mersen |
|---|---|
| Part Number # : | USCC1I-AC300 |
| SKU #: | 2450507 |
| Amperage Rating: | 30 A |
| Class: | CC |
| Dimensions: | 3.07 in H x 0.69 in W x 2.32 in D |
| Number of Poles: | 1 |
| Suitable For Use With: | ATDR, ATMR and ATQR Fuses |
| Temperature Rating (Degrees F): | -40 to 85 deg C |
| Wire Size: | 14 to 6 AWG |
| Connection type: | Pressure Plate |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | MERSEN |
| UNSPSC: | 39121624 |
| UPC: | 00782001831639 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$973.80 / 12Each
Typical price:$1794.94 / Each
Quantity:
- Mersen UltraSafe Fuse Holder, 300 V AC, 30 A, 1 Pole, Class: CC, Pressure Plate, 14 to 6 AWG Wire, DIN Rail Mount, -40 to 85 deg C, For Use With: ATDR, ATMR and ATQR Fuses, Polyamide, 3.07 in H x 0.69 in W x 2.32 in D
USCC1I-AC300 Application
For all circuits up to 600 V for motors, control circuits, transformers, DC circuits up to 1000 VDC including photovoltaic applicationsUSCC1I-AC300 Item Features
- IP20 finger safe (touch safe)
- Optional visual blown fuse indicator lights
- Compact footprint
- Quick, tool-free, easy fuse change outs
- 14.75 in-lb torque rating
- UL 94-v0 flammability rating
- No load-break disconnect
- Pressure plate connector
USCC1I-AC300 Standards
UL 4248-4 File No E52283|CSA C22.2|IEC 60269-2-1|60947-3 CompliantSKU #2450507Part Number #USCC1I-AC300UNSPSC39121624UPC00782001831639
