Part Number # 203C0120G
SKU # 2319565
203C0120G
Remke 203C0120G Micro-Link Tuff-Link Plug Assembly
Part Number # 203C0120G
SKU # 2319565
Remke 203C0120G Key Features
| Brand: | Remke |
|---|---|
| Part Number # : | 203C0120G |
| SKU #: | 2319565 |
| Keyway: | Dual Key |
| NEMA Rating: | NEMA 6P |
| Type: | Braided |
| Wire Pin Colors: | Black/Green/Red/White |
| Cable length: | 12, 12 ft |
| Cable type: | Stranded/Braided |
| UNSPSC: | 32151904 |
| UPC: | 00785411802190 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Remke 203C0120G Micro-Link Tuff-Link Plug Assembly
Brand: Remke
Part Number: 203C0120G
Remke Micro-Link Tuff-Link Plug Assembly, Braided, Female Connector, PVC, Stranded/Braided Cable, 12 ft Cable Length, PVC Cable, 3 Poles, Dual Key Keyway, 250 VAC/300 VDC, 4 A, 90 deg, Wire Pin Colors: Black/Green/Red/White, IP67 IEC Rating, NEMA 6P
Additional Description: RMKE-203C0120G DUAL KEY MICRO-LINK PLUG ASSEMBLY, PVC BRAIDED, FEMALE 90 DEG, 3 POLE, 12', 22 AWG PVC BRAIDED, FEMALE 90, 3 POLE, PLUG ASSEMBLIES: 90 DEGREE PLUG BRAIDED
Catalog Description: Dual Key Micro-Link Plug Assembly, PVC Braided, Female 90 deg, 3 pole, 12', 22 AWG
203C0120G Application
Automotive Assembly, Sensors on Conveyors, Pick and Place Robots, Packaging Machinery, Automated Machinery and Materials Handling Equipment Applications203C0120G Item Features
- Machined contacts (instead of stamped contacts) for highly accurate tolerances
- Gold plated brass contacts for enhanced corrosion resistance and conductivity
- High impact-resistant contact carriers for longer product life
- Vibration-resistant design so the connector will stay securely fastened to the sensor or mating receptacle
- Fast and easy replacement of 12 to 18 mm sensors, switches and control components
- Shielded and splitter styles
- PVC which is best for general assembly applications
- US and European sensor connection compatibility
- Fast and easy replacement of 12 to 18 mm
203C0120G Standards
RoHS Compliant|RoHS 2011/65/EU|cUL File No. E165657|CSA File No. E165657SKU #2319565Part Number #203C0120GUNSPSC32151904UPC00785411802190
Image provided may only be a representation of final product and may include optional equipment
