Part Number # 403A0200K
SKU # 2376628
Brand: Remke
403A0200K
Remke 403A0200K Micro-Link Tuff-Link Plug Assembly
Part Number # 403A0200K
SKU # 2376628
$53.24 / Each
Typical price:$77.65 / Each
Remke 403A0200K Key Features
| Brand: | Remke |
|---|---|
| Part Number # : | 403A0200K |
| SKU #: | 2376628 |
| Amperage Rating: | 4 A |
| Cable Material: | Polyurethane |
| Connector Type: | Straight Female |
| IEC Rating: | IP67 |
| Keyway: | Dual Key |
| NEMA Rating: | NEMA 6P |
| Number of Poles: | 3 |
| Type: | Non-Braided |
| Wire Pin Colors: | Black/Green/Red/White |
| Cable length: | 20 ft |
| Cable type: | Stranded |
| Country of origin: | US |
| Manufacturer Name: | NSi Industries |
| UNSPSC: | 32151904 |
| UPC: | 00785411805887 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$53.24 / Each
Typical price:$77.65 / Each
Quantity:
- Remke Micro-Link Tuff-Link Plug Assembly, Non-Braided, Straight Female Connector, Polyurethane, Stranded Cable, 20 ft Cable Length, Polyurethane Cable, 3 Poles, Dual Key Keyway, 250 V AC/300 V DC, 4 A, Wire Pin Colors: Black/Green/Red/White, IP67 IEC Rating, NEMA 6P
403A0200K Application
Automotive Assembly, Sensors on Conveyors, Pick and Place Robots, Packaging Machinery, Automated Machinery and Materials Handling Equipment Applications403A0200K Item Features
- Machined contacts (instead of stamped contacts) for highly accurate tolerances
- Gold plated brass contacts for enhanced corrosion resistance and conductivity
- High impact-resistant contact carriers for longer product life
- Vibration-resistant design so the connector will stay securely fastened to the sensor or mating receptacle
- Fast and easy replacement of 12 to 18 mm sensors, switches and control components
- Shielded and splitter styles
- PUR for excellent abrasion resistance for high abuse areas
- US and European sensor connection compatibility
- Fast and easy replacement of 12 to 18 mm
403A0200K Standards
RoHS Compliant|RoHS 2011/65/EU|cUL File No. E165657|CSA File No. E165657SKU #2376628Part Number #403A0200KUNSPSC32151904UPC00785411805887
Image provided may only be a representation of final product and may include optional equipment
