Rittal 1034000 Enclosure
Part Number # 1034000
SKU # 2377313

1034000
Rittal 1034000 Enclosure
Part Number # 1034000
SKU # 2377313
Rittal 1034000 Key Features
| Brand: | Rittal |
|---|---|
| Part Number # : | 1034000 |
| SKU #: | 2377313 |
| Electrical Ratings: | 1000 V AC/1500 V DC |
| Insulation: | Foamed-In PU Seal |
| Series: | AX Series |
| UNSPSC: | 39121324 |
| UPC: | 00063988991459 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Prices are in USD. Orders shipped to Canada may be subject to duties, taxes and brokerage fees, collected by the carrier on delivery.
Rittal 1034000 Enclosure
Brand: Rittal
Part Number: 1034000
Rittal Enclosure, Compact, Series: AX Series, 300 mm Width, 210 mm D, 400 mm Height, NEMA 4, Lock: (1) 3 mm Double-Bit Cam, 1000 VAC/1500 VDC, Foamed-In PU Seal, Wall Mount, -20 to 80 deg C, Carbon Steel, Powder Coated
Additional Description: RTL -1034000 AX161208NC WHD: 300 X 400 X 210 MM 300 x 400 x 210mm
Catalog Description: AX Compact enclosure, WHD: 300x400x210 mm, carbon steel, with mounting plate, single-door, with one cam lock
1034000 Application
For indoor/outdoor use, protection against rain, foreign bodies, splashed water and hosed water and against damage caused by icing on the exterior of the enclosure1034000 Includes
250 mm W x 375 mm H x 2 mm THK Mounting Plate, 1.25 mm THK Housing, (1) 130 deg Swing Angle 1.5 mm THK Door and Punched Door Strip1034000 Item Features
- All enclosure panels may be taken directly from the packaging, without dismantling and machined
- Interior installation on a 25 mm pitch pattern, no machining required
- Wall mounting brackets are easily secured from the outside with a self-tapping screw while retaining the UL Listed
- A QR code on the enclosure, door and mounting plate allows seamless monitoring, from receipt of incoming goods through to delivery of the finished product
- Simple earthing, even retrospectively, using machined keyholes in the mounting plate and perforated door strip
- The door and cam lock are quickly fitted with no need for tools
- Up to 33% larger gland plates support cable entry with ever-higher packing densities
- Dipcoat primed powder-coated on the outside textured paint housing/door
1034000 Standards
cUL Listed|CSA Certified|IP 66|RoHS Compliant|UL Listed1034000 Warranty
24 monthsSKU #2377313Part Number #1034000UNSPSC39121324UPC00063988991459
Image provided may only be a representation of final product and may include optional equipment
