Rittal 3188940 TopTherm Cooling Unit
Image Disclaimers Message
Rittal 3188940 TopTherm Cooling Unit
Rittal 3188940 TopTherm Cooling Unit
Part #:3188940
SKU #: 2326445
Key Features
Part #:3188940
SKU #: 2326445
Brand: Rittal
Control Type: e+ Controller
Dimensions: 63 in H x 18 in W x 15 in D
Enclosure Type: IP55
Frequency Rating: 50/60, 50/60 Hz
Power Rating: 1.21/1.28, 1.21/1.28 kW
- A revolution in energy efficiency using innovative hybrid technology
- Average 75 energy savings with speed regulated components and heat pipe technology
- Suitable for international use due to a unique multi-voltage capability
- Longer service life of the components inside the enclosure and the cooling unit due to component friendly cooling
- Intuitive operation due to touch display and intelligent interfaces
- Identical mounting cutout (external mounting, partial internal mounting and full internal mounting) for four output categories
- 1.21 kW at 50 Hz (L35), 1.21 kW at 60 Hz (L35), 1.28 kW at 50 Hz (L35 L50), 1.28 kW at 60 Hz (L35 L50)
- 14330 Btu at 50 Hz (L35), 14330 Btu at 60 Hz (L35), 10304 Btu at 50 Hz (L30 L50), 10304 Btu at 60 Hz (L30 L50)
Rittal 3188940 TopTherm Cooling Unit
Rittal TopTherm Cooling Unit, 3-Phase, Series: SK Series, 380 to 480 VAC, 1.21/1.28 kW, 50/60 Hz, 10304/14330 Btu Capacity range, IP55, e+ Controller Control, Plug-In Terminal Strip, -20 to 60 deg C, Wall Mount, Carbon Steel, Light Gray, 63 in H x 18 in W x 15 in D
Additional Description: RTL -3188940 BLUE E+ AC 14343 BTU 380-480V 3PH 50-60HZ TYPE12 SIDEMTG, COMFORT CONTR, RAL7035, NANOCOATED CONDENSER, CONDE 380-480V 3PH 50-60HZ TYPE12 14343BTU, 380-480V, 3PH, 50-60HZ, TYPE 12
Catalog Description: Wall-mounted cooling units Blue e+, Total cooling output 2.00 to 6.00 kW, total cooling output L35L35 at 50Hz: 6824, material: Sheet steel, color: RAL 7035, supply includes: Assembly parts, description: A revolution in energy efficiency through innovative hybrid technology 75% energy saved due to speed-regulated components and heat pipe technology. Unique multi-voltage capability for worldwide use. Intuitive operation via touch display Identical mounting cut-out (external mounting, partial internal mounting and full internal mounting) for four output categories.
