Rittal 3342500 Enclosure Fan
Part Number # 3342500
SKU # 2307357
Rittal 3342500 Key Features
| Brand: | Rittal |
|---|---|
| Part Number # : | 3342500 |
| SKU #: | 2307357 |
| Air Flow Rate: | 282.5, 282.5 cfm |
| Amperage Rating: | 0.85 |
| Dimensions: | 44 mm H x 482.6 mm W x 200 mm D, 482.6 mm W x 200 mm D x 44 mm H |
| Motor Type: | AC |
| Sound Level: | 51, 51 dB |
| UNSPSC: | 40101604 |
| UPC: | 00639889220003 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Rittal 3342500 Enclosure Fan
Brand: Rittal
Part Number: 3342500
Rittal Enclosure Fan, 1-Phase, 115 VAC/24 VDC, 0.85 A, 51 dB Sound Level, 282.5 cfm Air Flow, Rack Mounting, AC Motor, 482.6 mm W x 200 mm D x 44 mm H Dimensions
Additional Description: RTL -3342500 (N) 19IN RACKMOUNT FAN TRAY 3 FANS 24VDC 105MM FAN DEPTH 24VDC NON-CANCELABLE, NON-RETURNABLE FANS 24VDC 105MM FAN DEPTH
Catalog Description: SK rack-mounted fan, for 482.6 mm (19"), 480 m³/h, 115-230 V, 1PH, 50/60 Hz, 24 V (DC), WHD: 482.6 x 44 x 200 mm
3342500 Application
Climate Control Solutions3342500 Includes
Fully Wired Unit Ready For Connection, Terminal Strip and Assembly Parts3342500 Item Features
- For energy efficient operation of the fan and filter units, we recommend using the enclosure internal thermostat, the speed control or the digital enclosure internal temperature display and thermostat
- Rack mounted fan with integral speed control and fault evaluation
- Mounting directly on the 482.6 mm level
3342500 Standards
RoHS CompliantSKU #2307357Part Number #3342500UNSPSC40101604UPC00639889220003
Image provided may only be a representation of final product and may include optional equipment
