Rittal 6372562 Comfort Panel Enclosure
Image Disclaimers Message
Rittal 6372562 Comfort Panel Enclosure
Rittal 6372562 Comfort Panel Enclosure
Part #:6372562
SKU #: 2231523
Key Features
Part #:6372562
SKU #: 2231523
Brand: Rittal
Finish: Natural Anodized
NEMA Rating: NEMA 12, NEMA 12/IP65
Panel Size: 520 mm W x 600 mm H, 600 mm H x 520 mm W
Depth: 152, 152 mm
Height: 708.5, 708.5 mm
- High thermal conductivity for optimum passive heat dissipation
- Low weight coupled with high stability
- Light gray corner pieces, graphite gray corner protectors
- Extruded aluminum housing, die cast zinc corner pieces, plastic corner protectors material
- Hinging on the longest side
Rittal 6372562 Comfort Panel Enclosure
Rittal Comfort Panel Enclosure, 628.5 mm Width, 152 mm Depth, 708.5 mm Height, NEMA 12 Rating, 520 mm W x 600 mm H Panel, Lock: Cam, Extruded Aluminum, Natural Anodized
Additional Description: RTL -6372562 (N) COMFORT PANEL - 520X600X152 MM BASE PROGRAM 152mm NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Comfort Panel, Support arm connection Ø 130 mm, material: Enclosure: Extruded aluminium section, Corner pieces: Die-cast zinc, Corner protectors: Plastic, color: Enclosure: Natural anodised., Corner pieces: RAL 7035, Corner protectors: similar to RAL 7024, description: Operating housing in a stylish / slimline design made from extruded aluminium sections for effective heat dissipation, with support arm cut-out Ø 130 mm or rectangular 120 x 65 mm to fit support arm system CP 60 / 120 / 180, service access from the front or rear, uniform all-round mounting channels for individual installation of accessories without machining, protection category IP 65, produkt group: The right enclosure to suit any application. Different designs for individual adaptation to your respective requirements. Huge range of standard products available from stock. Matched to the Rittal support arm and stand systems.
