Brand: Rittal
Rittal 9340610 OM Adapter
Image Disclaimers Message
Brand: Rittal
Rittal 9340610 OM Adapter
Brand: Rittal
Rittal 9340610 OM Adapter
Part #:9340610
SKU #: 2295683
$55.34/EA
Key Features
Part #:9340610
SKU #: 2295683
Brand: Rittal
Specifications: 690 VAC, 65 A, 3-Pole, 3-Phase, 2.5 to 16 sq-mm Wire Size, 1-Number of Support Rails
Suitable For Use With: 5/10 mm Cross Section H Busbars, 60 mm Center-to-Center Spacing Bar System
Color: Pale Gray
Material: Polyamide (PA 6.6)
$55.34/EA
- According to a heat dissipation test to IEC 61 439-1 a current carrying capacity of up to 80 A is supported
- Pale gray (RAL 7035) OM adapter
Specifications
Brand: Rittal
Specifications: 690 VAC, 65 A, 3-Pole, 3-Phase, 2.5 to 16 sq-mm Wire Size, 1-Number of Support Rails
Suitable For Use With: 5/10 mm Cross Section H Busbars, 60 mm Center-to-Center Spacing Bar System
Color: Pale Gray
Material: Polyamide (PA 6.6)
UNSPSC: 39121108
UPC: 00639889830127
Rittal 9340610 OM Adapter
Rittal OM Adapter, For Use With: 5/10 mm Cross Section H Busbars, 60 mm Center-to-Center Spacing Bar System, 690 VAC, 65 A, 3-Pole, 3-Phase, 2.5 to 16 sq-mm Wire Size, 1-Number of Support Rails, Polyamide (PA 6.6), Pale Gray
Additional Description: RTL -9340610 RILINE OM ADAPTER-65A 55MM, 1 DIN 55MM, 1 DIN
Catalog Description: RILINE OM ADAPTER-65A
Item Features
