9001KP7
Schneider Electric 9001KP7 Harmony Pilot Light
Part Number # 9001KP7
SKU # 2355415
$149.56 / Each
Schneider Electric 9001KP7 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | 9001KP7 |
| SKU #: | 2355415 |
| Base Type: | BA9s |
| Bezel/Housing: | Polished Chrome Metal/Thermoplastic Polyester |
| Enclosure Type: | NEMA 1/2/3/3R/4/6/12/13/IP66 |
| Environmental Conditions: | -13 to 158 deg F Operating, -40 to 158 deg F Storage |
| Lamp Type: | Incandescent |
| Lens Type: | Round |
| Series: | 9001K |
| Size: | 30, 30 mm |
| Style: | Style 9/Normal |
| Terminal Type: | Screw Clamp, Screw/Clamp |
| Type: | Type K Standard Transformer |
| Wattage: | 2, 2 VA |
| Country of origin: | MX |
| Mounting type: | Panel |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121534 |
| UPC: | 00785901008743 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$149.56 / Each
Quantity:
- Schneider Electric Harmony Pilot Light, Type K Standard Transformer, Series: 9001K, 220 to 240 V AC, 2 VA Wattage, Style 9/Normal Style, Round Lens, Incandescent Lamp, Bezel/Housing: Polished Chrome Metal/Thermoplastic Polyester, 30 mm Size, Round Shape, BA9s Base, Screw Clamp Terminal, NEMA 1/2/3/3R/4/6/12/13/IP66 Enclosure, Panel Mounting, Environmental Conditions: -13 to 158 deg F Operating, -40 to 158 deg F Storage
9001KP7 Application
Food and Beverage, Chemical, Mining, Mineral and Metal Processing, Pulp and Paper, Water and Wastewater, Automotive, Crane and Hoists, Machine Tools, Airport and Transportation, Textile, Heavy Industries, Robust, Signaling and Hazardous Locations Applications9001KP7 Includes
Lamp9001KP7 Item Features
- Without legend plates, color cap
- Fingersafe contact blocks and light modules for improved safety
- Interchangeable light modules, contact blocks, color caps, pilot light lenses and mushroom heads reduce inventory
- Low cost incandescent lamps
- Proven technology
- Full size and shallow depth light modules
9001KP7 Standards
RoHS Compliant|UL File No. E78403 CCN NKCR|CSA File No. LR25490 Class 3211 03|CE Certified|EN/IEC 60947-1|EN/IEC 60947-5-1|EN/IEC 60947-5-4|EN/IEC 60529|JIS C 4520/852|UL 508|CSA File No. 14|Green Premium|REACH Compliant|WEEE Compliant|ECCN: EAR99|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov9001KP7 Warranty
18 MonthsSKU #2355415Part Number #9001KP7UNSPSC39121534UPC00785901008743
