Schneider Electric 9001SKR9R Harmony Non-Illuminated Push-Pull Operator
Image Disclaimers Message
Schneider Electric 9001SKR9R Harmony Non-Illuminated Push-Pull Operator
Schneider Electric 9001SKR9R Harmony Non-Illuminated Push-Pull Operator
Part #:9001SKR9R
SKU #: 35696
Key Features
Part #:9001SKR9R
SKU #: 35696
Brand: Schneider Electric
Bezel/Housing: Black
Enclosure Type: NEMA 1/2/3/3R/4/4X/6/12/13/IP66, NEMA 1/2/3/4/12/13/3R/4X/6/IP66
Operator Type: Mushroom Head
Series: 9001SK
Size: 30, 30 mm
- 1.81 in W x 2.72 in D x 1.77 in H dimension
- Round shape of signaling unit head
- Mushroom 41 mm Dia (unmarked marking) operator profile
- 5000000 cycles mechanical durability
- TC protective treatment
- Class II conforming to IEC 61140 electrical shock protection class
- 7 gn (2 to 500 Hz) conforming to IEC 60068-2-6 vibration-resistance
- 50 gn conforming to IEC 60068-2-27 shock-resistance
- -40 to 70 deg C storage temperature
- 1.18 in Dia mounting
- Without contact block
Schneider Electric 9001SKR9R Harmony Non-Illuminated Push-Pull Operator
Schneider Electric Harmony Square D Non-Illuminated Push-Pull Operator, Type K Dusttight Oiltight Watertight Heavy Duty Round, Series: 9001SK, 30 mm Size, Maintained Contact Mode, Mushroom Head Operator, 600 VAC, NEMA 1/2/3/3R/4/4X/6/12/13/IP66 Enclosure, Panel Mounting, Bezel/Housing: Black, -25 to 70 deg C, Plastic, Red
Additional Description: SQD -9001SKR9R 30MM PUSH-PULL OPERATOR RED KNOB +OPTIONS
Catalog Description: 30mm Push Button, Type SK, push pull operator, red mushroom cap
