Part Number # CA2KN31F7
SKU # 36295
CA2KN31F7
Schneider Electric CA2KN31F7 Tesys Control Relay
Part Number # CA2KN31F7
SKU # 36295
Schneider Electric CA2KN31F7 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | CA2KN31F7 |
| SKU #: | 36295 |
| Amperage Rating: | 10, 10 A |
| Coil Voltage: | 110, 110 V AC, 110 VAC |
| Contact Form: | 3NO-1NC, 3NO-1NC 3 Form A/1 Form B |
| Contact Rating: | 10 A at 600 V AC, 10 A at 600 VAC |
| Dimensions: | 1.77 in W x 2.24 in D x 2.28 in H, 45 mm W x 57 mm D x 58 mm H |
| Enclosure Type: | IP2X |
| Frequency Rating: | 400, 400 Hz |
| Series: | K Series |
| Temperature Rating (Degrees F): | -20 to 50 deg C, -25 to 50 |
| Terminal Type: | Screw Clamp |
| Country of origin: | ID, US |
| Mounting type: | Surface |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39122331 |
| UPC: | 00785901993032 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Schneider Electric CA2KN31F7 Tesys Control Relay
Brand: Schneider Electric
Part Number: CA2KN31F7
Schneider Electric Square D TeSys Control Relay, Series: K Series, 10 A, 400 Hz Frequency, 110 VAC Coil, 3NO-1NC Contact Form, 10 A at 600 VAC Contact, Surface Mounting, Screw Clamp Terminal, IP2X Enclosure, -20 to 50 deg C, 45 mm W x 57 mm D x 58 mm H Dimensions
Additional Description: SQD -CA2KN31F7 K CONTROL RELAY 3NO 1NC 110V AC COIL +OPTIONS
Catalog Description: Control relay, TeSys K, 3 NO + 1 NC, lt or eq to 690V, 110VAC coil
CA2KN31F7 Application
For use with control circuit applicationsCA2KN31F7 Standards
CE Certified|CSA File No. LR43364 Class 3211 03|ECCN EAR99|NF F 16-101|NF F 16-102|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65warnings.ca.gov|RoHS Compliant|UL 94-V-1 Flammability Rating|UL File No. 164353 CCN NKCRSKU #36295Part Number #CA2KN31F7UNSPSC39122331UPC00785901993032
Image provided may only be a representation of final product and may include optional equipment
