Part Number # EJB14015
SKU # 2442360
Image Disclaimers Message
Brand: Schneider Electric
EJB14015
Schneider Electric EJB14015
Part Number # EJB14015
SKU # 2442360
$334.68 / Each
Typical price:$408.00 / Each
Schneider Electric EJB14015 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | EJB14015 |
| SKU #: | 2442360 |
| Amperage Rating: | 15 A |
| Dimensions: | 5.66 in H x 0.98 in W x 4.05 in D |
| Frame: | E |
| Frequency Rating: | 50/60 Hz |
| Interrupt Rating: | 100 kA at 240 VAC, 65 kA at 480Y/277 VAC |
| Number of Poles: | 1 |
| Phase: | 1 |
| Temperature Rating (Degrees F): | 104 deg F |
| Trip Range: | 270 to 875 A |
| Trip Type: | Thermal Magnetic, Thermal/Magnetic |
| Type: | Type EJB |
| Wire Size: | 12 to 6 AWG Al, 14 to 6 AWG Cu |
| Connection type: | Lug |
| Country of origin: | MX |
| Material: | Thermoset Composite Resin |
| Mounting type: | Bolted-On |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121603 |
| UPC: | 00785901130499 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$334.68 / Each
Typical price:$408.00 / Each
Quantity:
- Square D Miniature Circuit Breaker, Type EJB, 277 V AC, 15 A, 50/60 Hz Frequency, 100 kA at 240 V AC, 65 kA at 480Y/277 V AC Interrupt, E Frame, Thermal Magnetic Trip, 270 to 875 A Trip, 1 Pole, 1 ph, Lug Connection, 12 to 6 AWG Al, 14 to 6 AWG Cu Wire, Bolted-On Mounting, 104 deg F, 5.66 in H x 0.98 in W x 4.05 in D Dimensions, Thermoset Composite Resin
EJB14015 Item Features
- Superior overload and short circuit protection
- From 15A to 125A ratings
- Troubleshoot faster with Visi-Trip
- These breakers provide a wide variety of robust features for use in panelboards
EJB14015 Standards
RoHS Compliant|CSA File No. LR92886|Federal Specification W-C-375B/GEN|HACR Rated|NOM 117|cULus Listed|UL 489 File No. E84967|PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.govSKU #2442360Part Number #EJB14015UNSPSC39121603UPC00785901130499
