Part Number # EJB14025
SKU # 2448031
Image Disclaimers Message
EJB14025
Schneider Electric EJB14025
Part Number # EJB14025
SKU # 2448031
Square D EJB14025 Key Features
| Brand: | Square D |
|---|---|
| Part Number # : | EJB14025 |
| SKU #: | 2448031 |
| Amperage Rating: | 25 A |
| Dimensions: | 4.05 in L x 0.98 in W x 5.66 in H |
| Frame: | E |
| Frequency Rating: | 50/60 Hz |
| Interrupt Rating: | 65 kA at 120/240/277 VAC, 100 kA at 120 VAC |
| Number of Poles: | 1 |
| Phase: | 1 |
| Temperature Rating (Degrees F): | 40 deg C |
| Trip Range: | 270 to 875 A |
| Trip Type: | Thermal Magnetic, Thermal/Magnetic |
| Type: | Type EJB |
| Wire Size: | 12 to 6 AWG Al, 14 to 6 AWG Cu |
| Connection type: | Lug |
| Country of origin: | MX |
| Material: | Thermoset Composite Resin |
| Mounting type: | Bolted-On |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121603 |
| UPC: | 00785901130512 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Schneider Electric EJB14025
Brand: Square D
Part Number: EJB14025
Square D™ Miniature Circuit Breaker, Type EJB, 277 VAC, 25 A, 50/60 Hz Frequency, 65 kA at 120/240/277 VAC, 100 kA at 120 VAC Interrupt, E Frame, Thermal/Magnetic Trip, 270 to 875 A Trip, 1 Pole, 1 ph, Lug Connection, 12 to 6 AWG Al, 14 to 6 AWG Cu Wire, Bolted-On Mounting, 40 deg C, 4.05 in L x 0.98 in W x 5.66 in H Dimensions, Thermoset Composite Resin
Additional Description: SQD -EJB14025 MINIATURE CIRCUIT BREAKER 277V 25A
Catalog Description: Mini circuit breaker, E-Frame, 25A, 1 pole, 277VAC, 100kA max, bolt on [TAA]
EJB14025 Application
HID Rated and Panelboard ApplicationsEJB14025 Item Features
- Superior overload and short circuit protection
- From 15A to 125A ratings
- Troubleshoot faster with Visi-Trip
EJB14025 Standards
RoHS Compliant|CSA File No. LR92886|Federal Specification W-C-375B/GEN|HACR Rated|NOM 117|cULus Listed|UL 489 File No. E84967|PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.govSKU #2448031Part Number #EJB14025UNSPSC39121603UPC00785901130512
