LC1D1286G7
Schneider Electric LC1D1286G7 Tesys D Iec Contactor
Part Number # LC1D1286G7
SKU # 2225559
$164.17 / Each
Schneider Electric LC1D1286G7 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | LC1D1286G7 |
| SKU #: | 2225559 |
| Coil Power Rating: | 7 to 7-1/2, 7 to 7-1/2 VA |
| Coil Voltage: | 120/690 VAC, 300 VDC |
| Contact Configuration: | 2NO-2NC |
| Dimensions: | 45 mm W x 92 mm D x 85 mm H, 85 mm H x 45 mm W x 92 mm D |
| Enclosure Type: | Open |
| Frequency Rating: | 50/60 Hz, 25 to 400 Hz |
| Number of Auxiliary Contacts: | 1 NO-1 NC, 2 |
| Number of Poles: | 4 |
| Operating Cycles: | 3600, 3600 Cycles/hr |
| Operating Temperature: | -4 to 70, -4 to 70 deg C, -5 to 60 |
| Series: | LC1D |
| Terminal Type: | Lugs Ring Tongue |
| Type: | Non-Reversing |
| Connection type: | Ring Tongue |
| Country of origin: | FR, SG |
| Mounting type: | Rail/Surface |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121529 |
| UPC: | 00785901611714 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$164.17 / Each
Quantity:
- Schneider Electric TeSys D IEC Contactor, Non-Reversing, Series: LC1D, 120/690 VAC, 300 VDC Coil, 25 A Maximum Load Current, 7 to 7-1/2 VA Coil, 4 Pole, 50/60 Hz, 25 to 400 Hz Frequency, 2NO-2NC Contact Configuration, 1 NO-1 NC Auxiliary Contacts, Ring Tongue Connection, Lugs Ring Tongue Terminal, Open Enclosure, 3600 Cycles/hr Operating Cycles, -4 to 70 deg C Operating, Rail/Surface Mounting, 45 mm W x 92 mm D x 85 mm H Dimensions
LC1D1286G7 Application
Industry, Infrastructure, Building, Resistive Load and Motor Control ApplicationLC1D1286G7 Item Features
- Designed to control and provide overload protection to motors rated up to 100 hp at 480 VAC or 125 hp at 600 VAC, TeSys D meets your needs for a majority of motor starter applications
- New TeSys D green increase TeSys D range with a new electronic coil with up to 80% less consumption than TeSys D standard AC or DC coil
- TeSys D green contactor simplify your maintenance services with 90% less references needed
- TeSys D green contactor associated with TeSys LR9D electronic overload relay reduces heat generation and energy consumption up to 50%
- High fault short circuit current ratings provide the flexibility to select any component, as long as it meets or exceeds the desired SCCR
- All contactors include built-in auxiliary contacts
- All screw connections have IP20 finger safe terminals with both North American and international terminal markings
- Designed for perfect integration in control systems
- Can be used to create motor starters for any type of application
- 120 VAC at 50/60 Hz, power circuit, 690 VAC at 25 to 400 Hz power circuit, 300 VDC
- Without built-in suppressor module
LC1D1286G7 Standards
Bureau Veritas Approved|CCC Certified|CSA C22.2 No. 14|DNV Certified|ECCN: EAR99|EN 60947-4-1/60947-5-1|Green Premium|GoST-R Certified|GL Certified|IEC 60947-4-1/60947-5-1|Lloyds Register Certified|RoHS Compliant|REACH Compliant|RINA Certified|UL 508|WEEE Compliant|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.p65warnings.ca.govSKU #2225559Part Number #LC1D1286G7UNSPSC39121529UPC00785901611714
