Part Number # LC1K0601F72
SKU # 2461059
LC1K0601F72
Schneider Electric LC1K0601F72
Part Number # LC1K0601F72
SKU # 2461059
$69.57 / Each
Schneider Electric LC1K0601F72 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | LC1K0601F72 |
| SKU #: | 2461059 |
| Coil Power Rating: | 4.5 VA |
| Coil Voltage: | 110 V AC |
| Contact Configuration: | 3NO-1NC |
| Contact Rating: | 10 A at 122 deg F Signalling Circuit, 20 A at 122 deg F Power Circuit |
| Dimensions: | 1.77 in W x 2.24 in D x 2.28 in H |
| Enclosure Type: | IP2X |
| Frequency Rating: | <=400 Hz |
| Number of Poles: | 3 |
| Operating Cycles: | 3600 Cycles/hr |
| Operating Temperature: | -58 to 176 deg F |
| Series: | TeSys K |
| Terminal Type: | Screw Clamp |
| Country of origin: | FR |
| Mounting type: | DIN Rail/Surface |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121529 |
| UPC: | 03389110487923 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$69.57 / Each
Quantity:
- Schneider Electric Contactor, Series: TeSys K, 110 V AC Coil, 6 A Maximum Load Current, 4.5 VA Coil, 3 Poles, <=400 Hz Frequency, Instantaneous Contact, 3NO-1NC Contact Configuration, 10 A at 122 deg F Signalling Circuit, 20 A at 122 deg F Power Circuit Contact, Screw Clamp Terminal, IP2X Enclosure, 3600 cycles/hr Operating Cycles, -58 to 176 deg F Operating, DIN Rail/Surface Mounting, 1.77 in W x 2.24 in D x 2.28 in H Dimensions
LC1K0601F72 Application
Material Handling an Hoisting ApplicationsLC1K0601F72 Item Features
- Designed to meet needs of various applications under 16A AC-3
- Optimized size to save customer cabinet space
- Wide range of accessaries to satisfy different customer usage
- Easier to install and operate with multi-standard screws
- Environmental performance of the product
- Designed for simple control systems
- https://www.youtube.com/watch?v=ITuDz_GqQd8
LC1K0601F72 Standards
BS 5424|CSA Certified|ECCN: EAR99|Green Premium Listed|IEC 60947|NF C 63-110|RoHS Compliant|UL Listed|VDE 0660|PROP65: This product can expose you to chemicals including, Lead and lead compounds which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.P65warnings.ca.gov.SKU #2461059Part Number #LC1K0601F72UNSPSC39121529UPC03389110487923
Image provided may only be a representation of final product and may include optional equipment
