LC2K09015E7
Schneider Electric LC2K09015E7 TeSys K Contactor
Part Number # LC2K09015E7
SKU # 2412329
$182.38 / Each
Schneider Electric LC2K09015E7 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | LC2K09015E7 |
| SKU #: | 2412329 |
| Coil Power Rating: | 4.5 VA |
| Coil Voltage: | 48 VAC |
| Contact Configuration: | 3NO |
| Contact Rating: | 20/10 A |
| Dimensions: | 90 mm W x 57 mm D x 58 mm H |
| Enclosure Type: | IP20 |
| Frequency Rating: | <=400 Hz |
| Number of Auxiliary Contacts: | 1NC |
| Number of Poles: | 3 |
| Operating Cycles: | 3600 Cycles |
| Operating Temperature: | -25 to 50 deg C |
| Series: | LC2K |
| Terminal Type: | Solder Pin |
| Type: | Reversing |
| Connection type: | Screw |
| Country of origin: | FR |
| Mounting type: | Surface |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121529 |
| UPC: | 00785901145950 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$182.38 / Each
Quantity:
- Schneider Electric Square D TeSys K Contactor, Reversing, Series: LC2K, 48 VAC Coil, 20 A Maximum Load Current, 4.5 VA Coil, 3 Pole, <=400 Hz Frequency, 3NO Contact Configuration, 1NC Auxiliary Contacts, 20/10 A Contact, Screw Connection, Solder Pin Terminal, IP20 Enclosure, 3600 Cycles Operating Cycles, -25 to 50 deg C Operating, Surface Mounting, 90 mm W x 57 mm D x 58 mm H Dimensions
LC2K09015E7 Application
For motor control and resistive loadLC2K09015E7 Item Features
- IP20 finger-safe terminals with both North American and International terminal markings
- Mountable on 35 mm DIN rail or panel mount with screws
- High-fault short circuit current ratings provide the flexibility to select any component, as long as it meets or exceeds the desired SCCR
- Simple to select the right product
- Control circuit flexibility
LC2K09015E7 Standards
CB Scheme;CCC;UL;CSA;EAC;CE;UKCASKU #2412329Part Number #LC2K09015E7UNSPSC39121529UPC00785901145950
