LP1D65004BD
Schneider Electric LP1D65004BD Iec Contactor
Part Number # LP1D65004BD
SKU # 2263681
Schneider Electric LP1D65004BD Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | LP1D65004BD |
| SKU #: | 2263681 |
| Coil Voltage: | 24, 24 VDC |
| Contact Configuration: | 4NO |
| Dimensions: | 127 mm H x 85 mm W x 182 mm D |
| Enclosure Type: | Open |
| Frequency Rating: | 25 to 400, 25 to 400 Hz |
| Number of Auxiliary Contacts: | 1NO-1NC |
| Number of Poles: | 4 |
| Operating Cycles: | 3600, 3600 Cycles/hr |
| Operating Temperature: | -5 to 60, -5 to 60 deg C |
| Series: | TeSys D LP1D, TeSys™ D LP1D |
| Terminal Type: | Screw Clamp, Screw/Clamp |
| Type: | Non-Reversing |
| Mounting type: | Plate/Rail |
| UNSPSC: | 39121529 |
| UPC: | 00785901846291 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Schneider Electric LP1D65004BD Iec Contactor
Schneider Electric Square D™ IEC Contactor, Non-Reversing, Series: TeSys™ D LP1D, 24 VDC Coil, 80 A Maximum Load Current, 4 Pole, 25 to 400 Hz Frequency, 4NO Contact Configuration, 1NO-1NC Auxiliary Contacts, Screw Clamp Terminal, Open Enclosure, 3600 Cycles/hr Operating Cycles, -5 to 60 deg C Operating, Plate/Rail Mounting, 127 mm H x 85 mm W x 182 mm D Dimensions
Additional Description: SQD -LP1D65004BD (N) 4P CONTACTOR 80A AC-1 24VDC COIL NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Schneider Electric,CONTACTOR 575VAC 65AMP IEC +OPTIONS,24 V DC,4 NO,4P,80 A at <= 60 °C for power circuit-10 A at <= 60 °C for control circuit,LP1D,contactor,LP1D,resistive load,TeSys D,rail-plate
LP1D65004BD Specifications
- AC, DC, low consumption DC control circuit
- TeSys™ D contactors have been designed for perfect integration in control systems
- They can be used to create motor starters for any type of application
LP1D65004BD Item Features
- AC, DC, low consumption DC control circuit
- TeSys D contactors have been designed for perfect integration in control systems
- They can be used to create motor starters for any type of application
SKU #2263681Part Number #LP1D65004BDUNSPSC39121529UPC00785901846291
