Part Number # LP1K12103BD3
SKU # 2449198
Image Disclaimers Message
LP1K12103BD3
Schneider Electric LP1K12103BD3
Part Number # LP1K12103BD3
SKU # 2449198
$147.35 / Each
Schneider Electric LP1K12103BD3 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | LP1K12103BD3 |
| SKU #: | 2449198 |
| Coil Voltage: | 24 V DC, 24 VDC |
| Contact Configuration: | 3NO-1NO |
| Contact Rating: | 20 A |
| Dimensions: | 2.28 in H x 1.77 in W x 2.24 in D |
| Frequency Rating: | 50/60 Hz |
| Number of Auxiliary Contacts: | 1 NO |
| Number of Poles: | 3 |
| Operating Cycles: | 3600 Cycles |
| Operating Temperature: | -13 to 122 deg F |
| Series: | LP1K Series |
| Size: | 2.28 in H x 1.77 in W x 2.24 in D |
| Type: | Contactor |
| Country of origin: | SG |
| Mounting type: | Front/Plate Rail |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121529 |
| UPC: | 03389110247886 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$147.35 / Each
Quantity:
- Schneider Electric LP1K12103BD3, Contactor, LP1K Series, 24 V DC Coil, 12 to 20 A Maximum Load Current, 3 Pole, 50/60 Hz Frequency, 3NO-1NO Contact Configuration, 1 NO Auxiliary Contacts, 20 A Contact, 2.28 in H x 1.77 in W x 2.24 in D Size, 3600 cycles Operating Cycles, -13 to 122 deg F Operating, Front/Plate Rail Mounting, 2.28 in H x 1.77 in W x 2.24 in D Dimensions
LP1K12103BD3 Application
For motor applicationsLP1K12103BD3 Item Features
- TeSys K contactors and overload relays are ideal for general duty applications where small size and reliability are key concerns
- A The special armature structure design allows all devices and all operating coils, either AC or DC, to have the same physical size and panel footprint for convenience
- Devices are available with low consumption DC operating coils for direct connection to PLC circuits
- Resistive loadMotor control contactor application
- Built-in bidirectional peak limiting diode suppressor coil technology
- Power circuit 600 V UL 508Power circuit 690 V IEC 60947-4-1Signalling circuit 690 V IEC 60947-4-1Signalling circuit 690 V IEC 60947-5-1Signalling circuit 600 V UL 508Power circuit 600 V CSA C22.2 No 14Signalling circuit 600 V CSA C22.2 No 14 ui rated insulation voltage
- 8 kV uimp rated impulse withstand voltage
- III overvoltage category
- V1 conforming to UL 94Requirement 2 conforming to NF F 16-101Requirement 2 conforming to NF F 16-102 flame retardance
- 3 mOhm - Ith 20 A 50 Hz power circuit average impedance
- 30 to 40 ms coil energisation and NO closing10 ms coil de-energisation and NO opening operating time
- B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1 safety reliability level
- 10 Mcycles mechanical durability
- 2000 m without derating operating altitude
- With toxic heavy metal free
LP1K12103BD3 Standards
CSA|UL Listed|UL Certified|RoHS Compliant|REACh CompliantCSA Certified|EAC Certified|PROP65: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov|CCC Certified|IEC CertifiedSKU #2449198Part Number #LP1K12103BD3UNSPSC39121529UPC03389110247886
