Brand: Square D (Schneider Electric)
Schneider Electric LZ1H6X5BD
Part Number # LZ1H6X5BD
SKU # 2470421
Brand: Square D (Schneider Electric)
LZ1H6X5BD
Schneider Electric LZ1H6X5BD
Part Number # LZ1H6X5BD
SKU # 2470421
$277.20 / Each
Square D (Schneider Electric) LZ1H6X5BD Key Features
| Brand: | Square D (Schneider Electric) |
|---|---|
| Part Number # : | LZ1H6X5BD |
| SKU #: | 2470421 |
| Amperage Rating: | 6.5 A |
| Coil Voltage: | 24 V DC |
| Dimensions: | 3.90 in H x 0.89 in W x 4.51 in D |
| Enclosure Type: | IP20 |
| Motor Power: | 1.5 kW |
| Number of Poles: | 3 |
| Operating Cycles: | 30 cycles |
| Operating Temperature: | -13 to 86,86 to 158 deg F |
| Reset Type: | Automatic/Electrical/Manual |
| Series: | TESYS Series |
| Country of origin: | US |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121521 |
| UPC: | 03606485421131 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$277.20 / Each
Quantity:
- Schneider Electric LZ1H6X5BD, TESYS Series, 500 V AC, 6.5 A, 1.5 kW Motor, 24 VDC Coil, 3 Pole, Automatic/Electrical/Manual Reset, IP20 Enclosure, 30 cycles Operating Cycles, -13 to 86,86 to 158 deg F Operating, 3.90 in H x 0.89 in W x 4.51 in D Dimensions
LZ1H6X5BD Application
For one direction of rotation, an adjustable motor current 1, For indication of tripping and motor running, For control and protection of 3-phase motors up to 3kW, For ON/OFF motor running and remote reset after thermal tripping, 1C/O contact relay for fault, For power contacts procures ultra compactness, For control and power, it can be used for ambient temperatures from -25 to 70LZ1H6X5BD Item Features
- Long electrical life, can perform 30 million AC53a electrical cycles which make it reliable
- Up to 75% space reduction, which makes it suitable for all control cabinets
- 60% reduction of installation time by having embedded functions in one slim body
LZ1H6X5BD Standards
IEC 60947-4-2|UL 60947-4-1|PROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.gov|IEC 60947-4-2|UL 60947-4-1SKU #2470421Part Number #LZ1H6X5BDUNSPSC39121521UPC03606485421131
Image provided may only be a representation of final product and may include optional equipment
