Schneider Electric M9F11320 Multi 9 Miniature Circuit Breaker
Image Disclaimers Message
Brand: Schneider Electric
Schneider Electric M9F11320 Multi 9 Miniature Circuit Breaker
Brand: Schneider Electric
Schneider Electric M9F11320 Multi 9 Miniature Circuit Breaker
Part #:M9F11320
SKU #: 2384718
$246.08/EA
Key Features
Part #:M9F11320
SKU #: 2384718
Brand: Schneider Electric
Actuator Type: Toggle
Amperage Rating: 20, 20 A
Dimensions: 72 mm L x 54 mm W x 81 mm H
Enclosure Type: IP20/IP40
Frequency Rating: 50 to 60, 50 to 60 Hz
$246.08/EA
- Circuit protection against short circuit, overload currents
- The presence of the green strip guarantees physical opening of the contacts and allows operations to be performed on the downstream circuit in complete safety
- Overvoltage resistance
- High performance limitation
- Fast closing independent of the speed of actuation of the toggle
- Upstream or downstream connection
Specifications
Brand: Schneider Electric
Actuator Type: Toggle
Amperage Rating: 20, 20 A
Dimensions: 72 mm L x 54 mm W x 81 mm H
Enclosure Type: IP20/IP40
Frequency Rating: 50 to 60, 50 to 60 Hz
Interrupt Rating: 10, 10 kA
Number of Poles: 3
Series: C60N
Temperature Rating (Degrees F): -22 to 158, -22 to 158 deg F
Trip Range: 8.5 in AC/12 in DC
Trip Type: C-Curve/Thermal Magnetic
Voltage Rating: 240/415/440 VAC/125 VDC
Wire Size: 1 to 25, 1 to 25 sq-mm
Color: Gray
Connection type: Tunnel Terminal
Country of origin: BG
Mounting type: Clip-On/DIN Rail
Manufacturer Name: Schneider Electric
UNSPSC: 39121603
UPC: 00785901666776
Item FeaturesCircuit Protection Applications
Item Features
Item FeaturesBAA Compliant|CCC Certified|EAC/KC Certified|EN/IEC 60947-2|ECCN EAR99|RoHS Compliant
