Part Number # RXM4GB2U7
SKU # 2446576
Image Disclaimers Message
Brand: Schneider Electric
RXM4GB2U7
Schneider Electric RXM4GB2U7
Part Number # RXM4GB2U7
SKU # 2446576
$91.20 / 10Each
Schneider Electric RXM4GB2U7 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | RXM4GB2U7 |
| SKU #: | 2446576 |
| Amperage Rating: | 3 A |
| Coil Voltage: | 240 V AC, 240 VAC |
| Contact Form: | 4CO 4 Form C 4PDT, 4CO/4PDT |
| Contact Rating: | 12 A at 250 V AC/12 A at 28 V DC, 12 A at 250 VAC/12 A at 28 VDC |
| Dimensions: | 21 mm W x 27 mm H |
| Display Type: | Green LED |
| Enclosure Type: | IP40 |
| Frequency Rating: | 50/60 Hz |
| Number of Poles: | 4 |
| Series: | RXM Series |
| Temperature Rating (Degrees F): | -40 to 55 deg C |
| Terminal Type: | Flat Pin |
| Country of origin: | CN |
| Mounting type: | DIN Rail/Panel |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39122326 |
| UPC: | 00785901616078 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$91.20 / 10Each
Quantity:
- Schneider Electric Square D Zelio Miniature Plug-In Relay, Series: RXM Series, 3 A, 1.2 VA Power, 50/60 Hz Frequency, 240 V AC Coil, 4CO 4 Form C 4PDT Contact Form, 12 A at 250 VAC/12 A at 28 VDC Contact, 4 Pole, DIN Rail/Panel Mounting, Flat Pin Terminal, Green LED Display, IP40 Enclosure, -40 to 55 deg C, 21 mm W x 27 mm H Dimensions
RXM4GB2U7 Application
General purposeRXM4GB2U7 Item Features
- This Schneider Electric Zelio RXM miniature plug-in relay has a control coil voltage of 240Vac and has 4 changeover contacts quadruple pole double throw with a rating of 3 amperes
- It has plug-in terminals with LED indicator and lockable test button
- https://www.youtube.com/embed/R9__kuMEA5U
RXM4GB2U7 Standards
CSA C22.2 File No 14|CE Certified|IEC 61810-1|cULus E164862 CCN NLDX NLDX7|cURus E164862 CCN NLDX NLDX8|EN/IEC 61810-1|EN/IEC 60529|ECCN: EAR99|Lloyd|Green Premium|RoHS Compliant|REACH Compliant|UL 508|PROP65: This product can expose you to chemicals including: Nickel compounds and Di-isodecyl phthalate (DIDP) which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.govSKU #2446576Part Number #RXM4GB2U7UNSPSC39122326UPC00785901616078
