SSM3A325P7
Schneider Electric SSM3A325P7 Zelio Solid State Relay
Part Number # SSM3A325P7
SKU # 2422904
$143.91 / Each
Typical price:$154.99 / Each
Schneider Electric SSM3A325P7 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | SSM3A325P7 |
| SKU #: | 2422904 |
| Amperage Rating: | 25 A |
| Coil Voltage: | 180 to 280 V AC Control/48 to 660 V AC Load, 180 to 280 VAC Control/48 to 660 VAC Load |
| Contact Form: | 3NO, 3NO 3 Form A |
| Dimensions: | 3.46 in W x 3.54 in D x 4.87 in H |
| Enclosure Type: | IP20 |
| Series: | SSM3 |
| Temperature Rating (Degrees F): | -20 to 60 deg C |
| Terminal Type: | Screw |
| Type: | 3-Channel 3-Phase Zero Voltage Switching |
| Country of origin: | US |
| Mounting type: | DIN Rail |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39122333 |
| UPC: | 00785901504870 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$143.91 / Each
Typical price:$154.99 / Each
Quantity:
Schneider Electric SSM3A325P7 Zelio Solid State Relay
Brand: Schneider Electric
Part Number: SSM3A325P7
,SSR 3 CH, 25A@48-600VAC ZC, 180-280VAC
Additional Description: SQD -SSM3A325P7 3P SSR 25A@48-600VAC Zero,200-265VAC
Catalog Description: pre Assembled, Harmony Solid State Relays, 25A, DIN rail mount, zero voltage switching, input 180...280V AC, output 48...600V AC
SSM3A325P7 Application
Inductive Load ApplicationsSSM3A325P7 Item Features
- Lugs for panel mounting
- Built-in heat sink for heat dissipation
- Control input connection terminals
- Control input voltage LED indicator in green
- Bracket for mounting on 35 mm DIN rail
- Load output connection terminals
- 1 hp at 40 A 240 VAC, 2 hp at 40 A 380 VAC, 3 hp 40 A 480 VAC
SSM3A325P7 Standards
RoHS Compliant|CE Certified|EAC Certified|UL 508|IEC 60950-1|CSA C22.2 File No. 14|Green Premium Listed|REACH Compliant|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.govSKU #2422904Part Number #SSM3A325P7UNSPSC39122333UPC00785901504870
