Part Number # XB6EAA41P
SKU # 2454267
Image Disclaimers Message
XB6EAA41P
Schneider Electric XB6EAA41P
Part Number # XB6EAA41P
SKU # 2454267
$254.00 / 50Each
Typical price:$495.00 / Each
Schneider Electric XB6EAA41P Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | XB6EAA41P |
| SKU #: | 2454267 |
| Actuator: | Flush |
| Bezel/Housing: | Plastic |
| Contact Configuration: | 1CO |
| Contact Rating: | 1.5 A at 120 VAC, 1 A at 240 VAC, 0.7 A at 240 VAC, 1 A at 120 VAC, 1 A at 24 VDC, 0.7 A at 24 VDC, 0.2 A at 125 VDC, 0.15 A at 125 VDC |
| Enclosure Type: | IP65 |
| Environmental Conditions: | -40 to 158 deg F Storage Temperature, 14 to 131 deg F operation |
| Operator Type: | Spring Return |
| Series: | XB6E |
| Terminal Type: | Solder |
| Type: | Monolithic Round |
| Color: | Red |
| Country of origin: | CN |
| Material: | Plastic |
| Mounting type: | Panel |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39122216 |
| UPC: | 00785901397007 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$254.00 / 50Each
Typical price:$495.00 / Each
Quantity:
Schneider Electric XB6EAA41P
Brand: Schneider Electric
Part Number: XB6EAA41P
round red pushbutton Ø 16 - flush spring return - 1OC
Additional Description: SQD -XB6EAA41P ROUND PUSHBUREDN OIP65
Catalog Description: Monolithic push button, Harmony XB6E, round red flush, 16mm, spring return, 1CO
XB6EAA41P Standards
Green Premium Listed|Class II IEC 60536|IEC 60529|EN/IEC 60947-5-1|IEC 60947-5-1|CSA C22.2 14|JIS C 4520|UL File No. 508|JIS C 852|IEC 60947-1|CCC Certified|cULus Recognized|REACH Compliant|RoHS Compliant|WEEE Certified|PROP65: This product can expose you to chemicals including, Nickel compounds, which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.SKU #2454267Part Number #XB6EAA41PUNSPSC39122216UPC00785901397007
