Part Number # 55418401
SKU # 2457696
Image Disclaimers Message
Southwire 55418401 Key Features
| Brand: | Southwire |
|---|---|
| Part Number # : | 55418401 |
| SKU #: | 2457696 |
| Conductor Size: | 4/0 AWG |
| Conductor Type: | Stranded Aluminum |
| Jacket Color: | Black/Yellow |
| Number of Conductors: | 3 |
| Outside Diameter: | 1421 mil |
| Strands: | 18 |
| Temperature Rating (Degrees F): | 20 deg C |
| Type: | Triplex Secondary UD |
| Country of origin: | US |
| Insulation material: | Cross Linked Polyethylene |
| Length: | 1000 ft |
| Manufacturer Name: | Southwire Company |
| UNSPSC: | 26121514 |
| UPC: | 00003288659645 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
- Southwire Service Entrance Cable, Triplex Secondary UD, 600 V AC, 3 Conductors, Stranded Aluminum Conductor, 4/0 AWG Conductor, 1421 mil OD, 1000 ft Length, 18 Strands, Cross Linked Polyethylene Insulation, Black/Yellow Jacket, 20 deg C
55418401 Application
For secondary distribution and underground service55418401 Item Features
- 658 mil single phase nominal conductor Dia
- 315 A direct burial, 240 A in-duct ampacities
- Neutrals are triple yellow extruded stripe
- Conductors are durably surface printed for identification
- Two phase conductors and one neutral conductor are cabled together to produce the triplex cable configuration
55418401 Standards
ARRA Compliant|Buy American Act Compliant|UL Listed|ICEA S-105-692|ASTM StandardSKU #2457696Part Number #55418401UNSPSC26121514UPC00003288659645
