Part Number # 68580002
SKU # 2444731
Image Disclaimers Message
Southwire 68580002 Key Features
| Brand: | Southwire |
|---|---|
| Part Number # : | 68580002 |
| SKU #: | 2444731 |
| Amperage Rating: | 20 A |
| Conductor Size: | 12 AWG |
| Conductor Type: | Solid Copper |
| Jacket Color: | Black/Green/White |
| Jacket Material: | Aluminum |
| Number of Conductors: | 2 |
| Outside Diameter: | 0.4746 in |
| Strands: | 1 |
| Temperature Rating (Degrees F): | 75 to 90 deg C |
| Type: | Type MC/THHN |
| Country of origin: | US |
| Insulation material: | PVC |
| Length: | 1000 ft |
| Manufacturer Name: | Southwire Company |
| UNSPSC: | 26121517 |
| UPC: | 00003288634716 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
- Southwire Armorlite Building Wire, Type MC/THHN, Reel Packaging, 600 V AC, 20 A, 2 Conductors, Solid Copper Conductor, 12 AWG Conductor, 0.4746 in OD, 1000 ft Length, 1 Strands, PVC Insulation, Aluminum Jacket, Black/Green/White Jacket, 75 to 90 deg C
68580002 Application
For branch, feeder and service power distribution in commercial, industrial, institutional, multi-residential buildings, power, lighting, control and signal circuits68580002 Item Features
- Concealed or exposed installations
- Installation in cable tray and approved raceways
- http://images.salsify.com/video/upload/s--zW-WNHR_--/u0zmauowighupgujdymz
68580002 Standards
ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL 83|UL 1569|UL 1685|Federal Specification A-A59544|FT4/IEEE 1202 (70,000 Btu/hr) Vertical Cable Tray Flame Test|NEC Listed for use in UL 1, 2 and 3 Hour Through Penetration Firestop Systems CompliantSKU #2444731Part Number #68580002UNSPSC26121517UPC00003288634716
