Part Number # 9001KA33
SKU # 2165296
Image Disclaimers Message
9001KA33
Square D 9001KA33 Harmony Contact Block
Part Number # 9001KA33
SKU # 2165296
$37.23 / Each
Square D 9001KA33 Key Features
| Brand: | Square D |
|---|---|
| Part Number # : | 9001KA33 |
| SKU #: | 2165296 |
| Contact Configuration: | 1NC |
| Contact Rating: | 5 A at 300 V AC, 5 A at 300 VAC |
| Dimensions: | 1.59 in H |
| Enclosure Type: | IP66 |
| NEMA Rating: | NEMA 1/2/3/3R/4/12/13 |
| Operator Type: | Slow Break |
| Size: | 30, 30 mm |
| Terminal Type: | Screw Clamp |
| Contact material: | Gold Flashed |
| Country of origin: | MX |
| Material: | Amorphous Nylon |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39122216 |
| UPC: | 00785901716648 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$37.23 / Each
Quantity:
- Schneider Electric Harmony Square D Contact Block, 30 mm Size, 1NC Contact Configuration, 5 A at 300 V AC Contact, Gold Flashed Contact, Slow Break Operator, NEMA 1/2/3/3R/4/12/13 NEMA Rating, IP66 Enclosure, Screw Clamp Terminal, Amorphous Nylon, 1.59 in H Dimensions
9001KA33 Application
For use with 9001K series push buttons9001KA33 Item Features
- https://www.youtube.com/watch?v=z4UUZQz35-w&list=PLa7UGrWOTyjnMSGFb16ULXxkQpETEayVn
9001KA33 Standards
RoHS Compliant|Green Premium|REACH Compliant|WEEE Compliant|UL Listed|CSA Certified|CE Certified|UL File No. E42259 CCN NKCR|CSA File No. LR24590 Class 3211 03|JIS C 4520|JIS C 852|EN/IEC 60947-1|EN/IEC 60947-5-1|EN/IEC 60947-5-4|CSA C22.2 File No. 14|UL 508|PROP65: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.govSKU #2165296Part Number #9001KA33UNSPSC39122216UPC00785901716648
