Part Number # LC1G800EHEA
SKU # 2415375
Image Disclaimers Message
Brand: Square D
LC1G800EHEA
Square D LC1G800EHEA LC1G Contactor, 48 to 130 VAC/VDC V Coil, 800 A, 4NO Contact, 3 Poles
Part Number # LC1G800EHEA
SKU # 2415375
$5888.89 / Each
Square D LC1G800EHEA Key Features
| Brand: | Square D |
|---|---|
| Part Number # : | LC1G800EHEA |
| SKU #: | 2415375 |
| Coil Voltage: | 48 to 130 V AC/DC, 48 to 130 VAC/VDC |
| Contact Configuration: | 4NO |
| Contact Rating: | 800 A at 440 V |
| Dimensions: | 15.30 in H x 8.31 in W x 10.47 in D |
| Enclosure Type: | IP2X |
| Frequency Rating: | 50/60 Hz |
| Number of Auxiliary Contacts: | 1NO-1NC |
| Number of Poles: | 3 |
| Operating Cycles: | 300 Cycles |
| Operating Temperature: | -13 to 140 deg F |
| Series: | LC1G |
| Terminal Type: | Lug-Ring |
| Wattage: | 70 W |
| Connection type: | Bolted |
| Country of origin: | CN |
| Mounting type: | Plate |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121529 |
| UPC: | 03606481922410 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$5888.89 / Each
Quantity:
- Schneider Electric, LC1G800EHEA, Contactor, Series: LC1G, 48 to 130 V AC/DC Coil, 800 A Maximum Load Current, 3 Pole, 50/60 Hz Frequency, 70 W Wattage, Auxiliary Contact, 4NO Contact Configuration, 1NO-1NC Auxiliary Contacts, 800 A at 440 V Contact, Bolted Connection, Lug-Ring Terminal, IP2X Enclosure, 300 Cycles Operating Cycles, -13 to 140 deg F Operating, Plate Mounting, 15.30 in H x 8.31 in W x 10.47 in D Dimensions
LC1G800EHEA Application
For Power switching, motor controlLC1G800EHEA Item Features
- Built-in Bidirectional peak limiting
LC1G800EHEA Standards
CB Scheme;CCC;cULus;EAC;CE;UKCA;EU-RO-MR by DNV-GL;EN/IEC 60947-4-1;EN/IEC 60947-5-1;UL 60947-4-1;CSA C22.2 No 60947-4-1;JIS C8201-4-1;JIS C8201-5-1;IEC 60335-1:Clause 30.2;IEC 60335-2-40:Annex JJ;UL 60335-1;UL 60335-2-40:Annex JJSKU #2415375Part Number #LC1G800EHEAUNSPSC39121529UPC03606481922410
