LC2D09BD
Square D LC2D09BD Tesys D Iec Contactor
Part Number # LC2D09BD
SKU # 357011
$292.25 / Each
Square D LC2D09BD Key Features
| Brand: | Square D |
|---|---|
| Part Number # : | LC2D09BD |
| SKU #: | 357011 |
| Coil Power Rating: | 5.4 W, 5.4 W Inrush/Hold-In |
| Coil Voltage: | 24, 690 V AC, 24/300 V DC, 690 VAC, 24/300 VDC |
| Contact Configuration: | 3NO |
| Contact Rating: | 10/60 A at 600 V AC, 25/60 A at 600 V AC, 10/60 A at 600 VAC, 25/60 A at 600 VAC |
| Dimensions: | 90 mm W x 95 mm D x 77 mm H, 90 mm W x 95 mm D x 82.5 mm H |
| Enclosure Type: | IP2X |
| Frequency Rating: | 50/60, 60 Hz |
| Number of Auxiliary Contacts: | 1NO-1NC, 2 |
| Number of Poles: | 3 |
| Operating Cycles: | 15000000, 3600 Cycles/hr |
| Operating Temperature: | -20 to 60/-40 to 70 deg C, -5 to 60 |
| Series: | LC2D |
| Size: | 77/90/95 mm |
| Terminal Type: | Screw Clamp |
| Type: | LC2D Standard, Mechanical Standard |
| Wattage: | 0.2/1.56 W, 4 |
| Connection type: | Screw Clamp |
| Country of origin: | FR, US |
| Mounting type: | Plate/Rail, Rail/Surface |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121529 |
| UPC: | 00785901207580 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$292.25 / Each
Quantity:
- Square D TeSys D IEC Contactor, Mechanical Standard, Series: LC2D, 690 V AC, 24/300 V DC Coil, 9/25 A Maximum Load Current, 5.4 W Coil, 3 Pole, 60 Hz, 0.2/1.56 W, Reversing Contact, 3NO, 1NO-1NC Auxiliary Contacts, 10/60 A at 600 VAC, 25/60 A at 600 VAC Contact, Screw Clamp, 77/90/95 mm, Screw Clamp Terminal, IP2X, 3600 cycles/hr Operating Cycles, -20 to 60/-40 to 70 deg C Operating, Rail/Surface Mount, 90 mm W x 95 mm D x 77 mm H
LC2D09BD Application
Motor Control and Resistive Load ApplicationsLC2D09BD Includes
Protective CoverLC2D09BD Item Features
- Built-in bi-directional peak limiting diode suppressor coil technology
- https://www.youtube.com/embed/kW01lFljKgE
LC2D09BD Standards
DNV;CSA;CCC;UL;GL;LROS (Lloyds register of shipping);BV;RINA;GOST;UKCALC2D09BD Warranty
18 monthsSKU #357011Part Number #LC2D09BDUNSPSC39121529UPC00785901207580
