Brand: Square D
Square D QOB315 Miniature Circuit Breaker
Image Disclaimers Message
Brand: Square D
Square D QOB315 Miniature Circuit Breaker
Brand: Square D
Square D QOB315 Miniature Circuit Breaker
Part #:QOB315
SKU #: 2209932
$778.71/3EA
Key Features
Part #:QOB315
SKU #: 2209932
Brand: Square D
Amperage Rating: 15, 15 A
Dimensions: 2.91 in L x 2.25 in W x 3 in H, 3 in H x 2.25 in W x 2.91 in D
Frame: QOB
Frequency Rating: 50/60, 50/60 Hz
Interrupt Rating: 10, 10 kA
$778.71/3EA
- Bolt-on QOB circuit breakers are for use in NQO and NQOD panel boards
- QO and QOB circuit breakers have Visi-Trip feature, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit
- 10 kA at 240 VAC, 5 kA at 48 VDC interrupt rating
- QO and QOB circuit breakers have an overcenter, trip-free toggle mechanism with quick-make, quickbreak action and positive handle indication
- The tripping mechanisms in two-and three-pole circuit breakers operate such that an overcurrent on any pole of the circuit breaker will cause all poles of the circuit breaker to open simultaneously
- 14 - 10 AWG copper, 14 - 8 AWG copper/aluminum
- Common trip
- Standard
Specifications
Brand: Square D
Amperage Rating: 15, 15 A
Dimensions: 2.91 in L x 2.25 in W x 3 in H, 3 in H x 2.25 in W x 2.91 in D
Frame: QOB
Frequency Rating: 50/60, 50/60 Hz
Interrupt Rating: 10, 10 kA
Number of Poles: 3
Phase: 3, 3 ph
Temperature Rating (Degrees F): 104, 40, 40 deg C
Trip Type: Thermal Magnetic, Thermal/Magnetic
Type: Standard
Voltage Rating: 240, 240 VAC, 240 VAC, 48 VDC
Wire Size: 14 to 10 AWG, 14 to 8 AWG, 14 to 8, 14 to 8 AWG
Connection type: Pressure Plate
Country of origin: MX, US
Mounting type: Bolt-On, Bolted-On
Manufacturer Name: Schneider Electric
UNSPSC: 39121603
UPC: 00785901417064
Square D QOB315 Miniature Circuit Breaker
Square D Miniature Circuit Breaker, 240 VAC, 48 VDC, 15 A, 50/60 Hz Frequency, 10 kA Interrupt, QOB Frame, Thermal/Magnetic Trip, 3 Pole, 3 ph, Pressure Plate Connection, 14 to 10 AWG, 14 to 8 AWG Wire, Bolted-On Mounting, 40 deg C, 3 in H x 2.25 in W x 2.91 in D Dimensions
Additional Description: SQD -QOB315 MINIATURE CIRCUIT BREAKER 240V 15A
Catalog Description: Mini circuit breaker, QO, 15A, 3 pole, 120/240VAC, 10kA, bolt on
Item FeaturesFor providing overload and short circuit protection
Item Features
Item FeaturesCSA C22.2 File No. 5|CSA Certified|PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov|RoHS Compliant|UL Listed|CSA 22.2 No. 5, HACR Rated|UL 489 Listed
