Symcom 201-200-SP Control Relay

Brand: Littelfuse

Part Number: 201-200-SP

Littelfuse® Symcom Time Mark® Voltage Monitoring Relay, 1-Phase, Series: 201-XXX-SP, 190 to 240 VAC, 50/60 Hz Frequency, SPDT Contact Configuration, 8 Pins, DIN Rail/Surface Mounting, 4 s Trip Delay, 1-3/4 in H x 2-3/8 in W x 4-1/8 in D Dimensions

Additional Description: LTFS-201-200-SP 1-PHASE PLUG-IN VOLTAGE MONITO

Catalog Description: The 201-xxx-SP is an 8-pin octal-base, plug-in voltage monitor designed to protect single-phase motors regardless of size. The 201-100-SP is used on 95-120VAC, 50/60Hz motors to prevent damage caused by low voltage. The 201-200-SP is used on 190-240VAC, 50/60Hz motors. The 201-200-SP-T-9 is a pin-for-pin replacement for a Time Mark; #260 Series voltage monitor. High voltage protection is included in the 201-200-SP-T-9. The unique microcontroller-based voltage and voltage-sensing circuit constantly monitors the voltage to detect harmful power line conditions. When a harmful condition is detected, the relay’s output relay is deactivated after a specified trip delay. The output relay reactivates after power line conditions return to an acceptable level and a specified amount of time has elapsed (restart delay). The trip delay prevents nuisance tripping due to rapidly fluctuating power line conditions.
