Littelfuse 250A-MET Key Features
| Brand: | Littelfuse |
|---|---|
| Part Number # : | 250A-MET |
| SKU #: | 2321039 |
| Amperage Rating: | 10 A |
| Contact Configuration: | 2 Form C DPDT, DPDT 2-Form C |
| Dimensions: | 2.93 in H x 5.27 in W x 2.95 in D |
| Frequency Rating: | 50 to 60 Hz |
| Trip Delay: | 4 s |
| Type: | 3-Phase |
| Country of origin: | MX |
| Mounting type: | Screw |
| Manufacturer Name: | Littelfuse |
| UNSPSC: | MISC |
| UPC: | 00079458990461 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$184.08 / Each
Typical price:$344.47 / Each
Quantity:
- Littelfuse, 250A-MET, Monitor, 3-Phase, 190 to 480 V AC, 10 A, 50 to 60 Hz Frequency, 2 Form C DPDT Contact Configuration, Screw Mounting, 4 s Trip Delay, 2.93 in H x 5.27 in W x 2.95 in D Dimensions
250A-MET Application
Used for any purpose not expressly set forth in applicable Littelfuse documentation250A-MET Item Features
- Proprietary microcontroller-based circuitry
- Constant monitoring of single-phase, low-voltage, voltage unbalance, phase reversal, harmful power line conditions
- Auto-sensing wide voltage range
- Automatically senses system voltage between 190-480 V ac.
- Saves setup time
- Advanced LED diagnostics
- Quick visual indicator for cause of trip
- Adjustable trip delay
- Prevents nuisance tripping due to rapidly fluctuating power line conditions
- DPDT relay output
- Allows for versatility to meet wide application needs
- Manual reset
- Allows for inspection of equipment before system is re-energized
250A-MET Standards
IEC 68-2-3SKU #2321039Part Number #250A-METUNSPSCMISCUPC00079458990461
