Part Number # D1.5/6.N.ADO
SKU # 2150635
Image Disclaimers Message
D1.5/6.N.ADO
TE Connectivity 1SNA199053R2000 Blue
Part Number # D1.5/6.N.ADO
SKU # 2150635
$84.00 / 50Each
Typical price:$108.40 / Each
TE Connectivity D1.5/6.N.ADO Key Features
| Brand: | TE Connectivity |
|---|---|
| Part Number # : | D1.5/6.N.ADO |
| SKU #: | 2150635 |
| Amperage Rating: | 17.5 A |
| Dimensions: | 45.5 mm H x 6 mm W x 41 mm D |
| Series: | SNA |
| Spacing: | 6 mm |
| Temperature Rating (Degrees F): | -55 to 110 deg C |
| Type: | Feed-Through |
| Color: | Blue |
| Country of origin: | FR |
| Material: | Polyamide |
| Mounting type: | DIN Rail |
| Manufacturer Name: | TE Connectivity |
| UNSPSC: | 39121410 |
| UPC: | 00662019964683 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$84.00 / 50Each
Typical price:$108.40 / Each
Quantity:
- TE, 1SNA199053R2000, Connector, Feed-Through, Series: SNA, 1 kV, 17.5 A, 6 mm Spacing, DIN Rail Mounting, -55 to 110 deg C, Polyamide, Blue, 45.5 mm H x 6 mm W x 41 mm D Dimensions
D1.5/6.N.ADO Application
For Feed-through applicationD1.5/6.N.ADO Item Features
- Screw clamp, stud technologies
- Available functions are feed-through, ground, disconnect, fuse, single to triple deck, test & measurement
- Power stud range available with stud-stud or stud-screw clamp technologies
- Ease the identification of functions inside cabinet thanks to large range of coloured variants
- The SNA connection technologies eliminate the need for retightening campaigns thanks dedicated anti-release system
- Avoid mounting and wiring errors thanks to asymmetrical design
- Allow installation flexibility with extra mounting options such as TS32 rail,panel or plate
- 50% faster assembly time thanks to the locking pin, 10 pre-assembled blocks plugged-in on rail at a time
- Elimination of faulty manouvers thanks to screw type jumper bars
D1.5/6.N.ADO Standards
EU RoHS Directive 2011/65/EU|EU ELV Directive 2000/53/EC|China RoHS 2 Directive MIIT Order No 32, 2016|Solder Process Capability|EU REACH Regulation (EC) No. 1907/2006SKU #2150635Part Number #D1.5/6.N.ADOUNSPSC39121410UPC00662019964683
