Telemecanique XCKN2902P20 Osisense Xc Limit Switch
Part Number # XCKN2902P20
SKU # 2439050
$48.74 / Each
Telemecanique XCKN2902P20 Key Features
| Brand: | Telemecanique |
|---|---|
| Part Number # : | XCKN2902P20 |
| SKU #: | 2439050 |
| Action: | Snap |
| Actuator: | Roller Plunger, Spring Return Roller Plunger |
| Amperage Rating: | 10 A |
| Connection type: | 1 x 0.34 to 2 x 1.5 sq-mm Screw Clamp Terminal |
| Contact Configuration: | 2NC |
| Country of origin: | FR |
| Enclosure Type: | IP65 |
| Environmental Conditions: | -40 to 70 deg C Storage |
| Material: | Plastic |
| Number of Poles: | 2 |
| Operating Cycles: | 5000000 cycles Electrical/10000000 cycles Mechanical |
| Operating Temperature: | -25 to 70 deg C |
| Series: | XCKN |
| Size: | 30 mm W x 30 mm D x 85 mm H |
| Type: | Standard Format Fixed |
| Manufacturer Name: | YAGEO Corporation |
| UNSPSC: | 39122213 |
| UPC: | 03389119034173 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$48.74 / Each
Quantity:
- Telemecanique OsiSense XC Limit Switch, Standard Format Fixed, Series: XCKN, 250 V DC/240 V AC, 10 A, 2NC, 2 Pole, 25 MOhm Closed Contact Resistance, Snap, Spring Return Roller Plunger, 1 x 0.34 to 2 x 1.5 sq-mm Screw Clamp Terminal, IP65 Enclosure, 30 mm W x 30 mm D x 85 mm H, 5000000 cycles Electrical/10000000 cycles Mechanical Operating Cycles, -25 to 70 deg C Operating, Plastic, Environmental Conditions: -40 to 70 deg C Storage
XCKN2902P20 Application
Electric Lift - Lifting Platforms/Elevators/Escalators, Packaging Machinery - Packaging Machines/Shrink Wrap Machines/Food and Beverage Machinery - Bottling/TextileXCKN2902P20 Item Features
- Simple - hundreds of complete switches can be assembled from a few stock components, reducing selection time and inventory
- Heads and levers are adjustable in 15 deg increments up to 360 degrees for precise and fast target alignment and are installed or interchanged quickly by releasing a lever instead of loosening multiple screws
- Damaged parts are easily replaced, saving you time and money over replacing the entire switch
- Economical - OsiSense XC switches offer a more cost effective solution for high volume OEMs combined with high performance - up to 10 million operations and proven reliability
- Linear plunger head
XCKN2902P20 Standards
RoHS Compliant|IEC 60204-1|IP65|IEC 60529|Green Premium|CSA Certified|REACH Compliant|Class II|IEC 61140|IEC 60068-2-6|IEC 60068-2-27|EN 50102|Class II NF C20-030|UL Listed|CCC|CSA C22.2 File No 14|IEC 60947-5-1|EN 60204-1|EN 60947-5-1|ECCN: EAR99|UL 508|PROP65: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP) and Diisononyl phthalate (DINP) which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.govSKU #2439050Part Number #XCKN2902P20UNSPSC39122213UPC03389119034173
